44506-5220 | Omron Emergency Cable Pull Switch Maintained Push-Button Reset IP67
- Regular price
- $389.00
- Sale price
- $389.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 44506-5220
Description
The Omron 44506-5220 Emergency Cable Pull Switch is a single-end maintained-action safety switch designed for reliable emergency stop control in conveyor and industrial equipment systems. It features a rugged die-cast alloy housing with IP67 and NEMA 6 ratings for protection in harsh environments. With a maximum cable span of 246 ft and push-button reset, it ensures dependable safety response and easy system restoration.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Safety and Control |
| Part Number | 44506-5220 |
| Subcategory | Emergency Pull Switches |
| Product Type | Single-Ended Emergency Cable Pull Switch |
| Action Type | Maintained |
| Reset Method | Push Button |
| Contact Form | 1NO / 2NC |
| AC Contact Rating | 3 A @ 240 V, 6 A @ 120 V |
| DC Contact Rating | 2.5 A @ 25 V |
| Thermal Current | 6 A |
| Min. Current | 5 mA |
| Operating Voltage | 120–240 VAC |
| Operating Force / Pull Force | 28 lb |
| Max. Cable Span | 246 ft (262 ft maximum) |
| Cable Connection Location | Left or Right |
| Mounting Style | Single End |
| Housing Material | Die-Cast Alloy |
| NEMA Rating | NEMA 6 |
| IP Rating | IP67 |
| Switching Ability | Single Cable |
| Indicator | None |
| Included Hardware | M5 × 4 Mounting Hardware |
| Compliances / Standards | UL, cUL, CE, TUV Listed |
| Compatible Models | 44506-0700, 44506-4700, 44506-4720, 44506-4731, etc. |
| Dimensions (L×W×D) | 8.74 × 3.78 × 3.39 in |
| Status | Active / New |
| Weight | Approx. 2.0 kg (4.4 lb) |
Information About 44506-5220
The 44506-5220 is part of Omron’s 44506 series of emergency cable pull switches, designed for use in safety interlock and stop control applications. This single-ended maintained-action model supports cable lengths up to 246 ft, providing flexibility in large conveyor installations. It features 1NO/2NC contacts with AC ratings of 3 A at 240 V and 6 A at 120 V, ensuring reliable electrical performance for control circuits. Its die-cast housing and corrosion-resistant construction make it suitable for demanding industrial environments where durability and operator safety are critical.
Key Features:
- Emergency Cable Pull Switch: Provides immediate stop capability across long conveyor systems.
- Single-End Mounting: Designed for single cable runs with left or right connection options.
- Maintained Action: Switch remains engaged until manually reset via push button.
- Wide Cable Span: Supports cable lengths up to 246 ft for extended installations.
- Durable Construction: Die-cast alloy housing with IP67 and NEMA 6 protection for harsh environments.
- Reliable Contact Configuration: Includes 1NO/2NC contact form for control circuit integration.
- High Electrical Rating: Rated 3A @ 240V AC and 6A @ 120V AC for robust industrial operation.
- Compliant Design: Certified to UL, cUL, CE, and TUV safety standards.
The 44506-5220 delivers the reliability and precision required for conveyor safety, machinery shutdown, and emergency stop systems.
