45692-001 | Lennox Universal Electronic Fan Timer Control Board
- Regular price
- $254.00
- Sale price
- $254.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 45692-001
Description
The Lennox 45692-001 is a universal electronic fan timer control board designed to replace OEM Honeywell timer boards in heating and cooling systems. It provides precise timing and control for blower motor operation, enhancing the performance, safety, and efficiency of HVAC systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Lennox |
| Category | HVAC Controls |
| Part Number | 45692-001 |
| Subcategory | Fan Timer Control Board |
| Type | Universal electronic timer board |
| Compatibility | Replaces Honeywell OEM timer boards |
| Function | Controls fan operation timing in heating and cooling systems |
| Power Supply | 24 VAC control circuit (low-voltage) |
| System Voltage | 120/240 VAC blower circuit interface |
| Mounting Type | Panel or chassis mounted within HVAC unit |
| Diagnostics | LED status indicators for system monitoring and troubleshooting |
| Temperature Range | -40°F to 150°F (-40°C to 65°C) typical |
| Connections | Multi-pin terminal block and spade connectors |
| Application | Residential and light commercial furnaces or air handlers |
| Certifications | UL Recognized Component |
| Weight | 3.00 lbs |
Information About 45692-001
The Lennox 45692-001 control board serves as a universal replacement electronic fan timer designed for Lennox HVAC systems and compatible Honeywell models. It provides reliable timing and switching functions that regulate the blower motor’s start and stop cycles during heating and cooling operation. The board ensures that the fan operates with the correct delay, preventing cold air discharge during startup and improving comfort and system longevity. Featuring durable construction and LED indicators for easy diagnostics, the 45692-001 simplifies troubleshooting and service. It installs easily in place of existing Honeywell boards, making it a practical choice for technicians and maintenance professionals handling Lennox systems.
Key Features
- Universal Replacement: Directly replaces OEM Honeywell timer boards used in Lennox HVAC systems.
- Precision Fan Timing: Controls blower delay-on and delay-off intervals for efficient air circulation.
- Integrated Relays: Provides coordinated switching for fan, heat, and cool circuits.
- Durable Construction: Built with high-quality electronic components and a protective PCB coating.
- Easy Installation: Universal design with labeled terminals ensures straightforward replacement.
- Diagnostic LED Indicators: Allows quick verification of board and system status.
- Energy Efficiency: Optimized fan operation reduces energy consumption and system wear.
- UL Recognized Safety Compliance: Meets reliability standards for residential and commercial HVAC systems.
The 45692-001 delivers the reliability and precision required for HVAC fan control, ensuring consistent system timing, safe operation, and long service life.
