505-DOD-XXX | Allen-Bradley NEMA Full Voltage Reversing Starter 3 Phase
- Regular price
- $4,999.00
- Sale price
- $4,999.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 505-DOD-XXX
Description
The Allen-Bradley 505-DOD-XXX is a NEMA Size 3 full voltage reversing starter designed to control 3-phase motor loads with forward and reverse functionality. It is an open-style starter with a 110V (50 Hz) / 120V (60 Hz) coil and is ready for field installation of an overload relay.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Contactors & Starters
|
| Part Number | 505-DOD-XXX |
| Subcatecory |
Starter
|
| NEMA Size | Size 3 |
| Phase | 3 Phase |
| Coil Voltage | 110V (50 Hz) / 120V (60 Hz) |
| Configuration | Reversing Starter |
| Mounting Style | Open (Panel Mount) |
| Overload Relay | Field-Installed (Provision Included) |
| Modifications | None (Standard Configuration) |
| Certifications | UL, CSA, CE, CCC, CUL, KC (Series Dependent) |
| Weight | 15.00 lbs |
Information About 505-DOD-XXX
The 505-DOD-XXX is a 3-phase motor starter from the Allen-Bradley 505 Series, built with reversing contactors for directional motor control in industrial applications. It is rated for NEMA Size 3 loads and features an open-style configuration, making it suitable for panel mounting and integration into control cabinets. The coil voltage supports both 110V at 50 Hz and 120V at 60 Hz, ensuring compatibility with global power systems. This model includes mounting provisions for a field-installed overload relay and carries no factory modifications, allowing flexible customization on site.
Key Features:
- Reversing Motor Control: built with forward and reverse contactors for directional operation of 3-phase motors.
- NEMA Size 3 Rating: supports moderate-to-large motor loads in commercial and industrial systems.
- Dual-Frequency Coil: operates with 110V @ 50 Hz and 120V @ 60 Hz for global compatibility.
- Open Style Configuration: designed for field or panel mounting with visible and accessible components.
- Overload Relay Provision: includes space and terminal support for user-installed overload protection.
- No Factory Modifications: ships standard for flexible customization and retrofit compatibility.
The 505-DOD-XXX provides robust and configurable reversing motor starting with NEMA-rated reliability, overload relay readiness, and open-panel accessibility.
