5069-L306ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 0.9MB
- Regular price
- $1,624.00
- Sale price
- $1,624.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 5069-L306ERS2
Description
The Allen-Bradley/Rockwell Automation 5069-L306ERS2 controller is a CompactLogix 5069 and Compact GuardLogix series industrial controller. It does not have many hardware requirements for installation or operation. This controller is equipped with 0.3 MB of safety memory and with 0.6 MB of user memory. The 5069-L306ERS2 controller supports 32 tasks with 1000 programs per task at a time.
Technical Specifications
| Brand | Allen-Bradley |
| Series | CompactLogix |
| Part Number | 5069-L306ERS2 |
| Safety Memory | 0.3 MB |
| Dimensions | 143.97 x 98.10 x 136.81 mm (5.67 x 3.86 x 5.39 in.) |
| Programming Languages | Sequential Function Chart, Function Block Diagram, Structured Text, and Ladder Diagram |
| Motion Axes, maximum | None |
| Integrated Motion | Yes |
| Communication rate, USB | 12 Mbps |
| Communication rate, Ethernet | 10 Mbps / 100 Mbps / 1 Gbps |
| Communication Ports | 1 Type B 2.0 Full-Speed USB and 2 Ethernet/IP Ports |
| Local I/O modules | 8 I/O modules |
| Supported Ethernet/IP Network Topologies | Device Level Ring, Star, and Linear |
| SIL Rating | SIL 2 |
| No. of tasks | 31 Standard tasks; 1 Safety Task |
| Non-volatile memory | 2GB via 1784-SD2 (ships with the controller) |
| Application Memory | 0.6 Megabytes |
| Module Type | Compact GuardLogix Controller |
| Product Type | Controller |
| Controller Tasks | 32 |
| Programs/task | 1000 |
| User Memory | 0.6 MB + 0.3 MB safety |
| Ports | 2 Ethernet |
| Port | 1 USB |
| Network Nodes | 16 |
Information About 5069-L306ERS2
The 5069-L306ERS2 is a Programmable Automation Controller (PAC) that is manufactured by Allen-Bradley. This controller is specifically a Safety controller that is part of the Compact GuardLogix controller product category. It features SIL 2 rating and embedded cpaabilities of a standard 5069-L306ER CompactLogix controller plus safety functionalities and specifications.
The 5069-L306ERS2 supports installation of up Eight (8) local Compact 5000 I/O modules which can be a mixture of standard and safety I/O modules. It also supports implementation of distributed I/O architecture over Ethernet with the use of a Compact 5000 Ethernet I/P adapter installed as the local adapter of the remote chassis. The controller communicates to each Distributed I/O assembly via the dual Ethernet I/P interfaces, embedded to the 5069-L306ERS2 controller. This communication ports support linear, star and Device Level Ring (DLR) topologies and support up to Sixteen 916) Ethernet I/P nodes and Thirty-Two (32) socket interfaces.
With the dedicated 0.3 MB safety memory, safety tasks may be downloaded to this controller. Safety tasks supported include Add-On Instructions, Controller logging, Integrated motion, Drive Safety Instructions, Ladder Diagram (LD), Language switching and Export program components.
For standard programming operation, the 5069-L306ERS2 tasks are configured and programmed using programming languages such as Ladder Diagram (LD), Structured Text (ST), Function Block Diagram (FBD), and Sequential Function Chart (SFC). While Safety task is configured using RLL and the additional safety application instructions.
This controller can support standard tasks and safety tasks, and it can use different programming languages depending on the type of tasks that it is currently handling. When the Allen-Bradley/Rockwell Automation 5069-L306ERS2 controller from the 5069 CompactLogix series is handling safety tasks, it uses the Ladder Diagram programming language. When the 5069-L306ERS2 controller is handling standard tasks on the other hand, it can use any one of several programming language options, including the Ladder Diagram (LD), Structured Text (ST), Function Block Diagram (FBD), and the Sequential Function Chart (SFC) programming languages.
When the 5069-L306ERS2 controller is connected to at least 1 or as many as 8 local I/O modules, these modules are Allen-Bradley Compact 5000 series I/O modules that are connected to the controller on the right side for a variety of applications.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
