Part #: 5069-L320ERS2 Manufactured by: Allen-Bradley
Regular price
$3,412.00
Sale price
$3,412.00
Regular price
7 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The Allen-Bradley 5069-L320ERS2 is a Compact GuardLogix Safety Integrity Level (SIL) 2 controller. This controller feature...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 5069-L320ERS2
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
    5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
    5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
    5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
    5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
    5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB
5069-L320ERS2 | Allen-Bradley GuardLogix 5380 Safety Controller, 3MB

Product Description P/N: 5069-L320ERS2

Description / Specifications

Description

The 5069-L320ERS2 controller is an Ethernet safety controller from the Allen-Bradley/Rockwell Automation Compact GuardLogix 5380 SIL 2 series. It features 1 MB of safety memory and 2 MB of user memory. The 5069-L320ERS2 Ethernet safety controller can handle 32 tasks that include 31 standard tasks and 1 safety task. The Ethernet network topologies that this controller supports include the DLR, star, and ring network topologies. The 5069-L320ERS2 Ethernet safety controller also has 2 embedded Ethernet ports that can communicate at speeds of 10 Mbps, 100 Mbps, and 1 Gbps.



Technical Specifications



Brand Allen-Bradley
Series CompactLogix
Part Number 5069-L320ERS2
Safety Memory 1 MB
Dimensions 143.97 x 98.10 x 136.81 mm (5.67 x 3.86 x 5.39 in.)
Programming Languages Sequential Function Chart, Function Block Diagram, Structured Text, and Ladder Diagram
Motion Axes, maximum None
Integrated Motion Yes
Communication rate, USB 12 Mbps
Communication rate, Ethernet 10 Mbps / 100 Mbps / 1 Gbps
Communication Ports 1 Type B 2.0 Full-Speed USB and 2 Ethernet/IP Ports
Local I/O modules Sixteen (16) I/O modules
Supported Ethernet/IP Network Topologies Device Level Ring, Star, and Linear
No. of tasks 31 Standard tasks; 1 Safety Task
Non-volatile memory 2GB via 1784-SD2 (ships with the controller)
Application Memory 2 Megabytes
Module Type Compact GuardLogix Controller
Product Type Controller
Controller Tasks 32
Programs/task 1000
User Memory 2 MB + 1 MB safety
Ports 2 Ethernet
Port 1 USB
Network Nodes 40





Information About 5069-L320ERS2

The Programmable Automation Controller (PAC) with catalog number 5069-L320ERS2 is a Compact GuardLogix controller from Allen-Bradley. It is part of the modern and enhanced version of PAC devices, being part of the CompactLogix 5380 product family. This controller series is specifically designed to meet the modern safety, control, connectivity and integration requirements of the industry. It is SIL 2 rated with 1oo2 architecture.

With the built-in Two (2) Ethernet interfaces, this controller is able to communicate with existing or newly installed Ethernet networks that implement Linear, Star and Ring topologies. These ports may function in Dual IP node wherein each port is assigned with unique IP address and Linear / DLR mode where both ports share the same IP address, acting as an integrated switch. These ports support transmission speed of 10 / 100 / 1000 Mbps transfer speed. In addition, the controller is provided with One (1) USB port which can perform all type of communication and function except industrial connectivity. This USB port supports up to 12 Mbps communication speed.

The 5069-L320ERS2 is a Compact GuardLogix controller has 2 MB user memory, dedicated for standard function and 1 MB safety memory for safety functionality. It also supports up to 32 Tasks wherein 31 tasks are for standard functions and the remining 1 task is exclusively assigned for safety task. Regardless of the type of task, each task can handle up to 1000 programs and utilize all event triggers made available to the controller.

This controller is DIN rail mounted device and powered by an external supply voltage of 18-32VDC with current of 475 mA. It has a power dissipation of 9.0 W and thermal dissipation of 30.9 BTU/hr.

This Compact GuardLogix controller accepts a maximum of 16 local I/O modules. The controller supports the dual-IP and linear/DLR modes along with the use of the Compact 5000 I/O modules as local or remote I/O modules. The controller can accept up to 40 nodes and 32 socket interfaces at a time. The unit also supports 31 standard controller tasks and 1 safety task. In addition to that, the controller has a user memory capacity of 2 megabytes and it also has 1 megabyte of safety memory. It can be used in nearly all non-hazardous industrial environments. The 5069-L320ERS2 controller has a MOD power voltage range of 18 to 32 Volts DC (SELV/PELV) and a maximum MOD power current rating of 475 milliamps. The MOD power inrush current rating is 1200 milliamps for a duration of 125 milliseconds. The controller has a continuous isolation voltage of 50 or 300 Volts, depending on the insulation type. The thermal dissipation rating of the 5069-L320ERS2 controller is 30.9 BTU per hour and the power dissipation rating of the controller is 9 Watts of power. Additionally, the controller has a USB 2.0 (Type B) programming port that is used for temporary connections, configurations, and updates. The 5069-L320ERS2 controller uses a Secure Digital (SD) card for storage and it mounts on a DIN rail. The controller's package includes a 2-gigabyte SD card. The size of the unit includes a height of 143.97 millimeters (5.67 inches), a width of 98.10 millimeters (3.86 inches), and a depth of 136.81 millimeters (5.39 inches). The approximate weight of the controller is 0.76 kilograms or 1.69 pounds.



Manufacturer information

Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.

IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
