5094-AEN2TR | Allen-Bradley Flex 5000 Dual-Port EtherNet/IP Adapter Module
- Regular price
- $959.00
- Sale price
- $959.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 5094-AEN2TR
Description
The Allen-Bradley/Rockwell Automation 5094-AEN2TR Ethernet adapter module is a FLEX 5000 series adapter module. It acts as an Ethernet adapter for FLEX 5000 series I/O modules. The 5094-AEN2TR Ethernet adapter module can serve up to 16 FLEX 5000 series I/O modules at a time. It supports copper media and it can support Ethernet speeds of up to 1 Gbps. The 5094-AEN2TR Ethernet adapter module supports star, linear, and DLR Ethernet network topologies.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Allen-Bradley |
| Adapter Type | FLEX 5000 EtherNet/IP Adapter with RJ45 Ports |
| Part Number | 5094-AEN2TR |
| Voltage and current ratings, MP | 18...32V DC, 1880 mA |
| Voltage and current ratings, MP inrush | 18...32V DC, 5700 mA for 100 ms |
| Voltage and current ratings, backplane | 15V DC, 1800 mA |
| Recommended external overcurrent protection | MOD Power: 10...12A @ 22.5...43.2 A2t, Fast ActingSA Power: 20 A @ 250V AC |
| Power dissipation, max | 6.2 W @ 18V DC |
| Thermal dissipation, max | 21.1 BTU/hr @ 24V DC |
| Isolation voltage | 300V (continuous), Basic Insulation Type Tested @ 2121V AC for 60 s, Power to Backplane and Backplane to Ethernet Tested @ 4242V DC for 60 s, Power to Ethernet ports No isolation between Ethernet ports |
| Wiring category | - on power ports. 1- on Ethernet ports |
| Wire type | Copper |
| Wire size, power RTB | 0.34...2.5 mm (22...14 AWG) solid or stranded copper wire rated at 105 °C (221 °F), or greater, 1.2 mm (3/64 in.) insulation, max, single wire connection only. Ferrule according to DIN 46 228/1. |
| Wire size, functional earth terminal | 2.5 mm (14 AWG) solid or stranded copper wire rated at 105 °C (221 °F), or greater, 3.5 mm (0.14 in.) max diameter including insulation, single wire connection only. |
Information About 5094-AEN2TR
The 5094-AEN2TR adapter is an RJ 45 enabled Ethernet/IP adapter designed and manufactured by Allen-Bradley. The adapter has been designed to facilitate high-speed data transfer across an Ethernet/IP network between a Flex 5000 Input/Output module and a Logix 5000 controller. This adapter variant can support up to 16 Flex 5000 I/O modules at a time. The adapter is meant to be used in an industrial environment only. It has an open enclosure and it can be used for indoor applications only. It can be mounted using a DIN Rail. A removable terminal block is also available in the adapter. The 5094-AEN2TR adapter is equipped with a reset lever and a DIN Rail latch side by side. The IP address label is placed on the front side of the adapter. There are two RJ 45 Ethernet ports alongside the functional earthing. The Ethernet address of the adapter is also placed with the ports.
The 5094-AEN2TR adapter is also equipped with LED status indicators. The LEDs show the machine status, NET activity, and transfer of data and information by using LINK 1 and LINK 2. It is also equipped with an IP address rotary switch along with the LED indicators. The adapter is certified with the c-UL-us, CE, RCM, KC, and other standards. It supports 18 to 32 Volts DC voltage and a current rating of 1880 milliamps. It supports an inrush current of 5700 milliamps for a time period of 100 milliseconds. The 5094-AEN2TR adapter works with a backplane current of 1800 milliamps and a backplane voltage of 15 Volts DC. The environment should be free from dust and dirt and harmful vapors and gases.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
