5KH36KNA510X | Marathon 1/4 HP Motor 1725/1425 RPM Dual-Voltage
- Regular price
- $849.00
- Sale price
- $849.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 5KH36KNA510X
Description
The Marathon 5KH36KNA510X is a versatile 1/4 HP AC induction motor built for dependable performance in industrial and commercial environments. Featuring dual-voltage capability (100–115V / 220–230V) and operating speeds of 1725/1425 RPM, this motor is well-suited for general-purpose applications. Its dripproof (DP) enclosure and 48Y frame ensure durability and compatibility with a wide range of equipment.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Marathon |
| Part Number | 5KH36KNA510X |
| Output Power | 0.25 HP |
| Voltage | 100–115V / 220–230V AC |
| Current Rating | 4.6 / 2.3 A |
| Speed | 1725 / 1425 RPM |
| Frequency | 50/60 Hz |
| Frame Size | 48Y |
| Enclosure Type | Dripproof (DP) |
| Housing Material | Cast Iron |
| Bearing Type | Permanently Lubricated, Sealed |
| Duty Cycle | Continuous |
| Free Air Flow Rate | 5 CFM |
| Maximum Vacuum | 26 in Hg |
| Inlet Size / Type | 1/4" NPT |
| Outlet Size / Type | 1/4" NPT |
| Fluid Compatibility | Air |
| Application | Pond Aeration / General Purpose |
Information About 5KH36KNA510X
The Marathon 5KH36KNA510X is engineered as a general-purpose AC motor, suitable for industrial machinery, air-moving equipment, pumps, aeration systems, and more. The motor’s dripproof (DP) enclosure protects internal components from moisture and debris, making it useful for environments such as pond aeration or ventilation applications where airflow and durability are essential. With dual-voltage flexibility (115/230 VAC) and a continuous-duty rating, the 5KH36KNA510X offers dependable long-term operation. The permanently lubricated sealed bearings minimize maintenance and enhance motor life, while the cast-iron housing ensures robust mechanical protection.
Key Features:
- 1/4 HP general-purpose AC motor
- Dual-voltage: 100–115V / 220–230V
- Speeds: 1725/1425 RPM (60 Hz / 50 Hz)
- Dripproof (DP) enclosure for reliable ventilation
- 48Y frame design for wide equipment compatibility
- Permanently lubricated sealed bearings
- Cast-iron housing for durability
- Continuous-duty operation
- 1/4" NPT inlet and outlet for air movement applications
- Suitable for pond aeration, light vacuum, HVAC, and general industrial use
The motor provides 5 CFM free-air flow, 26 in Hg maximum vacuum, and uses 1/4" NPT inlet and outlet ports—attributes that make it suitable for light-duty vacuum and air movement tasks. Designed for high efficiency and consistent torque output, this motor is a trusted solution across manufacturing, commercial, and utility-grade environments.
Description
The Marathon 5KH36KNA510X is a versatile 1/4 HP AC induction motor built for dependable performance in industrial and commercial environments. Featuring dual-voltage capability (100–115V / 220–230V) and operating speeds of 1725/1425 RPM, this motor is well-suited for general-purpose applications. Its dripproof (DP) enclosure and 48Y frame ensure durability and compatibility with a wide range of equipment.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Marathon |
| Part Number | 5KH36KNA510X |
| Output Power | 0.25 HP |
| Voltage | 100–115V / 220–230V AC |
| Current Rating | 4.6 / 2.3 A |
| Speed | 1725 / 1425 RPM |
| Frequency | 50/60 Hz |
| Frame Size | 48Y |
| Enclosure Type | Dripproof (DP) |
| Housing Material | Cast Iron |
| Bearing Type | Permanently Lubricated, Sealed |
| Duty Cycle | Continuous |
| Free Air Flow Rate | 5 CFM |
| Maximum Vacuum | 26 in Hg |
| Inlet Size / Type | 1/4" NPT |
| Outlet Size / Type | 1/4" NPT |
| Fluid Compatibility | Air |
| Application | Pond Aeration / General Purpose |
Information About 5KH36KNA510X
The Marathon 5KH36KNA510X is engineered as a general-purpose AC motor, suitable for industrial machinery, air-moving equipment, pumps, aeration systems, and more. The motor’s dripproof (DP) enclosure protects internal components from moisture and debris, making it useful for environments such as pond aeration or ventilation applications where airflow and durability are essential. With dual-voltage flexibility (115/230 VAC) and a continuous-duty rating, the 5KH36KNA510X offers dependable long-term operation. The permanently lubricated sealed bearings minimize maintenance and enhance motor life, while the cast-iron housing ensures robust mechanical protection.
Key Features:
- 1/4 HP general-purpose AC motor
- Dual-voltage: 100–115V / 220–230V
- Speeds: 1725/1425 RPM (60 Hz / 50 Hz)
- Dripproof (DP) enclosure for reliable ventilation
- 48Y frame design for wide equipment compatibility
- Permanently lubricated sealed bearings
- Cast-iron housing for durability
- Continuous-duty operation
- 1/4" NPT inlet and outlet for air movement applications
- Suitable for pond aeration, light vacuum, HVAC, and general industrial use
The motor provides 5 CFM free-air flow, 26 in Hg maximum vacuum, and uses 1/4" NPT inlet and outlet ports—attributes that make it suitable for light-duty vacuum and air movement tasks. Designed for high efficiency and consistent torque output, this motor is a trusted solution across manufacturing, commercial, and utility-grade environments.
