5PC720.1043-00 | B&R Panel PC 720
- Regular price
- $1,599.00
- Sale price
- $1,599.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 5PC720.1043-00
Description
The B&R Panel PC 720 (5PC720.1043-00) is a 10.4-inch industrial panel PC featuring a VGA color TFT display with resistive touchscreen. It is designed for reliable operation in harsh environments, offering versatile connectivity and IP65-rated protection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | B&R |
| Category | HMI (Human Machine Interfaces) |
| Part Number | 5PC720.1043-00 |
| Subcategory | HMI Operator Interfaces |
| Weight | 3.6 kgs |
| LEDs | Power, HDD, Link 1 |
| Diagonal | 10.4" (264 mm) |
| Colors | 262,144 |
| Resolution | VGA, 640 x 480 pixels |
| Contrast | 300:1 |
| USB Type | USB 2.0 |
| USB Transfer Rate | Low speed (1.5 Mbit/s), full speed (12 Mbit/s) to high speed (480 Mbit/s) |
| Ethernet Transfer Rate | 10/100 Mbit/s |
| Ethernet Max. Baud Rate | 100 Mbit/s |
| Audio Type | AC97 sound |
| Nominal Voltage | 24 VDC ±25% |
| Nominal Current | 3.8 A |
| Inrush Current | Typ. 10 A, max. 40 A for < 300 μs |
| Degree of Protection |
Front: IP65 Back: IP20 |
| Storage Temperature |
-30 to 70°C |
| Dimensions |
323 mm x 260 mm x 86.3 mm |
Information About 5PC720.1043-00
The B&R Panel PC 720 (model 5PC720.1043-00) is a robust industrial computer designed for demanding environments. It features a 10.4-inch VGA color TFT display with a resistive touchscreen, providing clear visuals and responsive interaction for various industrial applications.
Key Features:
- Display: 10.4-inch VGA color TFT with resistive touchscreen.
- Connectivity: Equipped with two RS232 ports, three USB 2.0 ports, two Ethernet 10/100 ports, AC97 sound, and PS/2 inputs for keyboard and mouse, allowing integration with a wide range of peripherals.
- Durability: Front panel rated at IP65, ensuring protection against dust and water ingress, suitable for harsh industrial conditions.
- Power Supply: Operates on 24 VDC power; requires a screw clamp terminal block (0TB103.9) or a cage clamp terminal block (0TB103.91) for connection, sold separately.
The Panel PC 720 is ideal for applications requiring reliable human-machine interface (HMI) solutions in industrial automation, process control, and machinery operation.
