6808 | Honeywell Silent Knight 198-Point Addressable Fire Alarm Control Panel with IP & POTs
- Regular price
- $1,234.00
- Sale price
- $1,234.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 6808
Description
The Honeywell Silent Knight 6808 is an intelligent addressable Fire Alarm Control Panel (FACP) designed for mid-sized commercial and institutional facilities. This advanced panel provides reliable fire detection, system integration, and flexible communication options including IP, POTs, and optional cellular connectivity. Supporting up to 198 addressable devices, the 6808 ensures efficient monitoring and control in modern fire protection systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell Silent Knight |
| Category | Fire Alarm Systems |
| Part Number | 6808 |
| Subcategory | Fire Alarm Control Panel |
| Device Type | Intelligent Addressable FACP |
| SLC Capacity | 99 detectors + 99 modules (198 SK devices) or 127 SD devices |
| Network Capability | Link up to 17 panels via copper or fiber |
| Communication | Built-in IP and POTs, optional cellular |
| Wireless Support | SWIFT® wireless detection compatible |
| Power Output | 4 Flexput circuits, 6A total output |
| Zones / Groups | 250 software zones, 250 output groups |
| Display | 4x20 LCD, 80-character |
| Programming Interface | Built-in USB port |
| Relays | 2 programmable Form C and 1 trouble relay |
| Certifications | UL 864, FM Approved, CSFM 7165-0559:0502, FDNY COA# 6246 |
| Primary Power | 120 VAC, 60 Hz, 3.3 A |
| Battery Support | 17–55 Ah capacity, holds up to two 18 Ah batteries |
| Cabinet Color | Red |
| Dimensions (H × W × D) | 26.37 × 16.36 × 3.91 in |
| Weight | 16 lbs |
Information About 6808
The 6808 is part of the Silent Knight IntelliKnight Series, engineered for scalability and interoperability across multi-panel networks. It supports one Signaling Line Circuit (SLC) capable of handling up to 99 detectors and 99 modules or 127 SD protocol devices. The panel is compatible with both copper and fiber-optic network connections, allowing up to 17 panels to be linked for unified system supervision. Equipped with advanced communication, USB programming, and SWIFT® wireless detection support, the 6808 combines flexibility, redundancy, and ease of configuration for professional fire protection installations.
Key Features
- Intelligent Addressable Control: Supports 198 SK devices or 127 SD devices on a single SLC loop.
- Network Connectivity: Links up to 17 panels for centralized monitoring using copper or fiber-optic connections.
- Dual-Path Communication: Built-in IP and POTs capabilities ensure continuous alarm reporting redundancy.
- Wireless Detection Ready: SWIFT® compatibility enables easy integration of wireless devices in hard-to-wire areas.
- Flexible Power Output: Four Flexput circuits configurable as NACs or auxiliary power, up to 6A total.
- Programmable Zones and Groups: Supports 250 software zones and 250 output groups for detailed control logic.
- User-Friendly Operation: Large 4x20 LCD with 80-character display and easy-to-use keypad for efficient navigation.
- Field-Upgradeable Firmware: Allows quick software updates without returning the unit for service.
The 6808 delivers the reliability and precision required for commercial-grade fire detection and alarm management systems.
Description
The Honeywell Silent Knight 6808 is an intelligent addressable Fire Alarm Control Panel (FACP) designed for mid-sized commercial and institutional facilities. This advanced panel provides reliable fire detection, system integration, and flexible communication options including IP, POTs, and optional cellular connectivity. Supporting up to 198 addressable devices, the 6808 ensures efficient monitoring and control in modern fire protection systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell Silent Knight |
| Category | Fire Alarm Systems |
| Part Number | 6808 |
| Subcategory | Fire Alarm Control Panel |
| Device Type | Intelligent Addressable FACP |
| SLC Capacity | 99 detectors + 99 modules (198 SK devices) or 127 SD devices |
| Network Capability | Link up to 17 panels via copper or fiber |
| Communication | Built-in IP and POTs, optional cellular |
| Wireless Support | SWIFT® wireless detection compatible |
| Power Output | 4 Flexput circuits, 6A total output |
| Zones / Groups | 250 software zones, 250 output groups |
| Display | 4x20 LCD, 80-character |
| Programming Interface | Built-in USB port |
| Relays | 2 programmable Form C and 1 trouble relay |
| Certifications | UL 864, FM Approved, CSFM 7165-0559:0502, FDNY COA# 6246 |
| Primary Power | 120 VAC, 60 Hz, 3.3 A |
| Battery Support | 17–55 Ah capacity, holds up to two 18 Ah batteries |
| Cabinet Color | Red |
| Dimensions (H × W × D) | 26.37 × 16.36 × 3.91 in |
| Weight | 16 lbs |
Information About 6808
The 6808 is part of the Silent Knight IntelliKnight Series, engineered for scalability and interoperability across multi-panel networks. It supports one Signaling Line Circuit (SLC) capable of handling up to 99 detectors and 99 modules or 127 SD protocol devices. The panel is compatible with both copper and fiber-optic network connections, allowing up to 17 panels to be linked for unified system supervision. Equipped with advanced communication, USB programming, and SWIFT® wireless detection support, the 6808 combines flexibility, redundancy, and ease of configuration for professional fire protection installations.
Key Features
- Intelligent Addressable Control: Supports 198 SK devices or 127 SD devices on a single SLC loop.
- Network Connectivity: Links up to 17 panels for centralized monitoring using copper or fiber-optic connections.
- Dual-Path Communication: Built-in IP and POTs capabilities ensure continuous alarm reporting redundancy.
- Wireless Detection Ready: SWIFT® compatibility enables easy integration of wireless devices in hard-to-wire areas.
- Flexible Power Output: Four Flexput circuits configurable as NACs or auxiliary power, up to 6A total.
- Programmable Zones and Groups: Supports 250 software zones and 250 output groups for detailed control logic.
- User-Friendly Operation: Large 4x20 LCD with 80-character display and easy-to-use keypad for efficient navigation.
- Field-Upgradeable Firmware: Allows quick software updates without returning the unit for service.
The 6808 delivers the reliability and precision required for commercial-grade fire detection and alarm management systems.
