6AV3688-3XY38-3AX0 | Siemens Blank Front for KP8 & KP8F
- Regular price
- $234.00
- Sale price
- $234.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 6AV3688-3XY38-3AX0
Description
The 6AV3688-3XY38-3AX0 is a KP8-format blank front panel designed for mounting 22.5 mm operator controls. It enables quick setup of modular operator panels and integration into PRO device extension units.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|---|---|
| Brand | Siemens |
| Category |
Controls & Indicators
|
| Part Number | 6AV3688-3XY38-3AX0 |
| Subcatecory |
Control Accessory
|
| Format | KP8 / KP8F |
| Compatible Controls | 22.5 mm Operator Elements |
| Compatibility | Extension Units of 15" and 19" 4:3 PRO devices |
| Installation | Front Mountable |
| Mounting Use | Modular Operator Panels |
| Scope of Supply | 1x KP8 Design Empty Front |
| Weight | 0,310 Kg |
| Packaging Dimension | 10,80 x 18,20 x 6,20 |
| Package size unit of measure | CM |
Information About 6AV3688-3XY38-3AX0
The 6AV3688-3XY38-3AX0 is a design empty front in the KP8 format from Siemens, developed to simplify the configuration of custom operator panels. Its layout is specifically tailored for the easy installation of standard 22.5 mm operator control elements, such as push buttons or selector switches, without additional machining or modification. This blank panel serves as an ideal interface base when building modular Human Machine Interfaces (HMI) in automation systems.
Key Features:
-
Flexible Panel Customization: KP8 format design enables modular operator panel setups tailored to specific needs.
-
Standardized Cutouts: Supports easy mounting of 22.5 mm standard operator controls without the need for drilling or custom fabrication.
-
Seamless PRO Integration: Fully compatible with extension units of all 15" and 19" 4:3 Siemens PRO devices.
-
Compact and Durable: Engineered for efficient use of space while maintaining structural integrity in industrial environments.
-
Simple Installation: Supplied as a complete blank panel—quick to mount and configure within an HMI system.
The 6AV3688-3XY38-3AX0 provides a standardized foundation for creating flexible and ergonomic operator panel configurations.
