Product Description P/N: 6AV6545-0BC15-2AX0

Description / Specifications

Description

The Siemens 6AV6545-0BC15-2AX0 is a SIMATIC TP170B Touch Panel designed for operator interface applications in industrial environments. With a 5.7-inch color touchscreen display, it provides intuitive control and monitoring capabilities for various automation processes.

Equipped with a RISC 32-Bit CPU running at 66MHz and 768KB of configuring memory, the touch panel offers reliable performance and responsiveness. It features multiple interface ports, including 1 x RS-422/485 for MPI/DP/PPI communication with speeds of up to 12 Mbit/s, 1 x RS-232/TTY for passive communication, and 1 x RS-232 for PLC/PC/Printer interface.


Technical Specifications



Part #

6AV6545-0BC15-2AX0

Manufacturer

SIEMENS

Category

HMI / MMI / OIT

Subcategory

Operator Interface

Design of display

STN

Screen diagonal

5.7 in

Size

5.7"

Display type

STN, 16 colors

Color type

Colors

Horizontal image resolution

320

Vertical image resolution

240

Resolution (WxH in pixel)

320 x 240

MTBF backlighting (at 25 °C)

about 50,000 hours

Control elements

Touch screen

Operating options

Touch

Touch screen

Analog, resistive

Supply voltage

24 V DC

Rated current

0.25 A

Power

7 W

Processor

RISC 32-bit, 66 MHz

Processor type

RISC 32-bit

Type

Flash / RAM

Usable memory for user data

768 KB usable memory for user data

Type of clock

Software clock, synchronizable, no battery backup

Battery-backed and synchronizable

No

Interfaces

TTY optional, 2 x RS232, 1 x RS422, 1 x RS485 (max. 12 Mbit/s)

Number of RS 485 interfaces

1

Transmission rate, max.

12 Mbit/s

CF card slot

1 x CF card slot

Front IP

IP65

Type of protection

IP20

IP (at the front)

IP65

Rear IP

IP20

Mounting position

Vertical

Maximum permissible angle of inclination

+/- 35 °

Transport, storage

-20 °C to +60 °C

Max. relative humidity

85 %

Operating system

Windows CE

Configuration tool

ProTool / Lite, Version 5.2 SP 2 or higher

Configuration tool

WinCC flexible Compact, Version 2004 or higher

1st configuration kit

ProTool / Lite, Version 5.2 SP 2

2nd configuration kit

WinCC flexible Compact, Version 2004


Information About 6AV6545-0BC15-2AX0



The Siemens 6AV6545-0BC15-2AX0 SIMATIC TP170B Touch Panel is an operator interface terminal designed for industrial applications. Featuring a 5.7-inch color touchscreen, it offers intuitive interaction and control in automation environments. The device is powered by a RISC 32-bit CPU running at 66MHz, ensuring efficient processing capabilities for various tasks.

With 768KB of configuring memory, the touch panel provides ample storage for user-defined configurations and settings. It includes multiple interface ports for enhanced connectivity, including 1 x RS-422/485 interface port (MPI/DP/PPI) supporting speeds of up to 12 Mbit/s, 1 x RS-232/TTY (passive) interface port for PLC interfacing, and 1 x RS-232 interface port for PLC/PC/printer interfacing.

The touch panel also features a CF card slot compatible with Card Type 1, enabling expandable storage options for data logging and application storage. Its 320x240 STN LCD screen supports 16 colors, ensuring clear and vibrant display of information and graphics in industrial environments.

Running on the Windows CE operating system, the touch panel offers stability and compatibility with industrial applications. It is configurable with ProTool Lite Version 5.2 SP2 and higher or WinCC flexible Compact Version 2004 and higher, providing flexibility in application development and customization.

The device operates on a 24V DC power supply, ensuring compatibility with standard industrial power systems. Its design and construction meet industrial standards for robustness and reliability, making it suitable for deployment in demanding industrial environments.


Manufacturer information

Siemens: A renowned global manufacturer, leading in technology, engineering, and innovation across diverse sectors for a sustainable future.

Warrany image

IQElectro 2 Year Warranty

IQElectro offers a 2-Year Warranty on all our products. This complimentary two-year warranty ensures that every purchase from IQElectro is a secure investment in the future of your company.
