6ES7132-1BL00-0XB0 | SIEMENS SIMATIC S5/S7, Electronic Block

Description

The Siemens 6ES7132-1BL00-0XB0 is a SIMATIC S7-300 digital output module designed for standard signal control in industrial automation. It provides 16 digital output channels for 24V DC switching.

Technical Specifications

Information About 6ES7132-1BL00-0XB0

The 6ES7132-1BL00-0XB0 is part of the Siemens SIMATIC S7-300 SM 132 I/O module family, developed to provide reliable digital signal output within modular automation systems. It offers 16 transistor (sourcing) outputs, each rated for 24V DC and 0.5 A, enabling direct control of solenoids, relays, and indicators. The module supports electronic short-circuit protection and features per-channel LED indicators for output status, simplifying diagnostics and maintenance. It communicates with the CPU via the S7-300 backplane bus and is configured using STEP 7 / TIA Portal software. Compact and rail-mounted, the 6ES7132-1BL00-0XB0 enables efficient output expansion in distributed or centralized control architectures.

Key Features:

• Design: Digital output module for SIMATIC S7-300 systems.
• Channels: 16 sourcing digital outputs.
• Output Rating: 24V DC, 0.5 A per channel.
• Protection: Built-in electronic short-circuit protection.
• Diagnostics: Per-channel LED indicators for output status.
• Integration: Communicates via the S7-300 backplane and configured in STEP 7 / TIA Portal.
• Installation: Compact rail-mounted design for modular expansion.
• Application Range: Ideal for machine automation, material handling, and process control.

The 6ES7132-1BL00-0XB0 delivers the reliable switching performance, diagnostics, and scalability required for digital output control in S7-300 automation systems.

Manufacturer information

Siemens: A renowned global manufacturer, leading in technology, engineering, and innovation across diverse sectors for a sustainable future.
