6ES7134-4GB01-0AB0 | Siemens SIMATIC DP, ET 200S 2-Channel Analog Input Module
- Regular price
- $179.00
- Sale price
- $179.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 6ES7134-4GB01-0AB0
Description
The Siemens 6ES7134-4GB01-0AB0 is a SIMATIC ET 200S analog input module designed to process two 4–20 mA analog current signals from standard 2-wire transmitters. With a 13-bit resolution and 65 ms conversion time per channel, it delivers reliable measurement performance for distributed automation applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Part Number | 6ES7134-4GB01-0AB0 |
| Part Category | PLC Systems |
| Product Family | SIMATIC S7 / ET 200S |
| Analog Inputs | 2 channels |
| Input Signal Range | 4–20 mA (2-wire) |
| Resolution | 13-bit |
| Conversion Time | 65 ms per channel |
| Sensor Type | Standard 2-wire transducers |
| Supply Voltage | 24 V DC (from ET 200S power module) |
| Current Consumption | 80 mA (L+), 10 mA (bus, 3.3 V) |
| Power Loss | 0.6 W typical |
| Address Space | 4 bytes per module |
| Max Cable Length (shielded) | 200 m |
| Status Indicators | SF LED (group fault) |
| Connection Type | Screw or spring-loaded terminals |
| Protection Rating | IP20 |
| Dimensions (W × H × D) | 15 × 81 × 52 mm |
| Mounting | DIN rail, front/side mounting |
| Explosion Protection | ATEX Gas Zone 2 (Category 3G) |
Information About 6ES7134-4GB01-0AB0
The 6ES7134-4GB01-0AB0 is part of the Siemens SIMATIC ET 200S distributed I/O system, designed for flexible and modular field-level automation. This analog module provides two 4–20 mA current inputs for direct integration of pressure transmitters, flow sensors, temperature converters, and general industrial analog devices. With a 65 ms channel update rate, the module delivers stable measurement performance suitable for process control, monitoring, and closed-loop regulation. Its 13-bit resolution supports accurate signal interpretation across the full current scale. The module includes a group fault (SF) LED, enabling rapid diagnostics for wiring errors, sensor faults, or configuration issues. It is powered through the ET 200S backplane and features screw or spring clamp terminals for easy field wiring.
Key Features:
- 2-channel analog input module for ET 200S distributed I/O
- Supports 4–20 mA standard process signals
- 13-bit resolution for reliable and accurate measurement
- 65 ms per channel conversion time
- SF (system fault) LED for fast diagnostics
- Powered directly from ET 200S backplane and L+ supply
- Compact 15 mm width for high-density installations
- ATEX Category 3G certified for gas-zone environments
- Suitable for process instrumentation and distributed automation
Built to integrate seamlessly into PROFIBUS or PROFINET systems via ET 200S interface modules, the 6ES7134-4GB01-0AB0 supports scalable expansion, long cable lengths (up to 200 m shielded), and flexible mounting options.
