6ES7134-6GD01-0BA1 | Siemens Simatic Et200sp Analog Current Input Module
- Regular price
- $185.00
- Sale price
- $185.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 6ES7134-6GD01-0BA1
Description
The Siemens 6ES7134-6GD01-0BA1 is a four-channel analog current input module designed for the ET 200SP distributed I/O platform. It provides high-precision current measurement with a 16-bit resolution for reliable signal acquisition in industrial automation systems.
Technical Specifications
| Condition | New / Never Used Surplus |
| Part Number | 6ES7134-6GD01-0BA1 |
| Manufacturer | Siemens |
| Category | PLCs/Machine Control |
| Subcategory | VDC Logic I/O Module |
| Analog Inputs | 4 |
| Resolution | 16-bit |
| Base Unit Type | A0, A1 |
| Supply Voltage | 24 VDC |
| Permissible Range | 19.2–28.8 VDC |
| Input Current | 37 mA (without sensor supply) |
| Short Circuit Protection | Yes |
| Dimensions (H × W × D) | 15 × 73 × 58 mm |
| Colour Code | CC03 |
| Ambient Temperature | 0°C to 60°C |
| Approvals | CE, EAC, cULus |
Information About 6ES7134-6GD01-0BA1
The Siemens 6ES7134-6GD01-0BA1 Analog Current Input Module is engineered for the SIMATIC ET 200SP Distributed I/O System, offering four 16-bit analog current inputs that support both 2-wire and 4-wire configurations. It is compatible with BU-Type A0 and A1 base units and follows Color Code CC03, ensuring easy identification and streamlined installation within mixed I/O racks. With a basic error limit of ±0.3%, the module delivers accurate current measurement suitable for demanding industrial processes, while its integrated diagnostics enhance monitoring and assist in rapid issue detection. Its compact 15 mm width allows for efficient space utilization in control panels, making it an ideal choice for high-density I/O environments requiring stable and precise current input performance.
Key Features
- High-Accuracy Current Measurement: Provides four analog current input channels with 16-bit resolution for precise signal acquisition.
- Flexible Wiring Options: Supports both 2-wire and 4-wire standard configurations for seamless integration with various industrial sensors.
- Comprehensive Diagnostics: Includes built-in diagnostic functions to detect wiring faults, short circuits, and operational irregularities.
- Compact Form Factor: Slim 15 mm module width enables dense installation in ET 200SP racks, optimizing control cabinet space.
- Base Unit Compatibility: Works efficiently with BU-Type A0 and A1, ensuring adaptability across ET 200SP configurations.
- Reliable Operating Performance: Offers a ±0.3% basic error limit, ensuring stable, accurate readings under industrial conditions.
The 6ES7134-6GD01-0BA1 delivers the reliability and precision required for advanced process monitoring, sensor integration, and distributed automation systems.
