6ES7134-6HB00-0CA1 | Siemens ET 200SP High-Feature 2-Channel Analog Input Module
- Regular price
- $214.00
- Sale price
- $214.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 6ES7134-6HB00-0CA1
Description
The Siemens 6ES7134-6HB00-0CA1 is a high-feature analog input module for the SIMATIC ET 200SP system, providing two differential channels for voltage and current measurement. It supports multiple signal ranges with 16-bit resolution and operates on a 24 VDC supply. Designed for cabinet I/O installations, this module offers plug-in mounting and LED status indication for efficient system integration.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | PLCs/Machine Control |
| Part Number | 6ES7134-6HB00-0CA1 |
| Subcategory | VDC Logic I/O Module |
| Product Series / Family | SIMATIC |
| Sub-Range | ET 200SP |
| Module Type | High-Feature Analog Input Module |
| Main Function | I/O Unit |
| Supply Voltage | 24 VDC |
| Operating Mode | MSI |
| Analog Inputs | 2 differential channels |
| Supported Signals | 0–10 V, 1–5 V, ±10 V, ±5 V, 0–20 mA, 4–20 mA |
| Resolution | 16-bit |
| Re-parameterization | Supported during operation |
| Calibration | Supported during operation |
| I&M Data | I&M0 to I&M3 |
| Digital Inputs | None |
| Analog Outputs | None |
| Display | LED Indicator |
| Design | Cabinet I/O |
| Color Code | CC05 |
| Mounting Mode | Plug-in |
| Degree of Protection | IP20 |
| Net Height | 73 mm |
| Net Width | 15 mm |
| Net Depth | 58 mm |
Information About 6ES7134-6HB00-0CA1
The 6ES7134-6HB00-0CA1 belongs to the SIMATIC ET 200SP family, offering cabinet-mounted high-precision analog input functionality for distributed automation systems. Its design supports voltage and current measurement with re-parameterization and calibration available during live operation, enhancing flexibility in process adjustments. The module operates in MSI mode and uses a compact plug-in form factor with CC05 color coding for clear identification. Typical usage includes monitoring of sensors, process instrumentation, and control signals where high resolution and stable analog measurement are required.
Key Features:
- Two HF analog inputs: Differential channels supporting voltage and current measurement.
- Wide signal range: Accepts 0–10 V, 1–5 V, ±10 V, ±5 V, 0–20 mA, and 4–20 mA inputs.
- High-feature performance: Includes live re-parameterization and calibration functions.
- 16-bit resolution: Ensures precise acquisition of analog process values.
- Plug-in cabinet design: ET 200SP format with easy installation and CC05 identifier.
- 24 VDC operation: Standardized supply voltage for industrial control systems.
- LED indication: Provides module and channel status visibility.
- Compact IP20 enclosure: Suitable for protected cabinet environments with minimal space requirements.
The 6ES7134-6HB00-0CA1 delivers the reliability and precision required for high-accuracy analog measurement in ET 200SP distributed I/O systems.
