6ES7134-6HD01-0BA1 | Siemens SIMATIC ET 200SP 4-Channel Analog Input Module
- Regular price
- $179.55
- Sale price
- $179.55
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 6ES7134-6HD01-0BA1
Description
The Siemens 6ES7134-6HD01-0BA1 is a SIMATIC ET 200SP analog input module designed for high-accuracy acquisition of current and voltage signals in distributed control systems. It provides four differential measurement channels with 24 V DC operation, enabling reliable monitoring of process values in compact automation environments. Its robust electrical design supports demanding industrial applications requiring precise analog data collection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | Analog Input Module |
| Part Number | 6ES7134-6HD01-0BA1 |
| Subcategory | SIMATIC ET 200SP I/O |
| Rated Voltage | 24 V DC |
| Voltage Range | 19.2–28.8 V DC |
| Reverse Polarity Protection | Yes |
| Number of Analog Inputs | 4 differential inputs |
| Max Input Voltage (Destruction Limit) | 30 V DC |
| Max Input Current (Destruction Limit) | 50 mA |
| Current Consumption (Max) | 37 mA (without sensor supply) |
| Power Loss (Typical) | 0.85 W |
| Supported Cable Length | Up to 1000 m (shielded), 200 m for voltage inputs |
| Module Width | 15 mm (ET 200SP form factor) |
| Mounting | Plug-in module for ET 200SP base units |
| Operating Temperature | 0…60 °C |
| Dimensions (L×W×H) | 6.80 × 7.70 × 2.40 cm |
Information About 6ES7134-6HD01-0BA1
The 6ES7134-6HD01-0BA1 is part of the Siemens SIMATIC ET 200SP family, developed for modular and space-saving distributed I/O integration. This AQ 2xU/I ST module supports two configurable analog outputs, selectable for voltage (±10V, 0–10V, 1–5V) or current (0/4–20mA) ranges. With 16-bit resolution, it ensures high accuracy for precise process control. The module includes built-in diagnostics such as wire break detection, short-circuit protection, and channel status reporting, improving reliability and simplifying troubleshooting. Integration with SIMATIC controllers via PROFINET provides fast and deterministic communication, while configuration is carried out in the TIA Portal engineering framework. Its compact design and hot-swappable capability make it ideal for flexible and scalable automation architectures.
Key Features:
- Design: Analog output module for ET 200SP distributed I/O.
- Channels: 2 configurable analog output channels.
- Signal Ranges: Supports voltage (±10V, 0–10V, 1–5V) and current (0/4–20mA).
- Resolution: 16-bit high-resolution output for precise signal generation.
- Diagnostics: Wire break, short-circuit detection, and channel fault monitoring.
- Integration: Seamlessly connects with SIMATIC controllers via PROFINET.
- Configuration: Parameterized and engineered in Siemens TIA Portal.
- Application Range: Suitable for process automation, machine control, and monitoring.
The 6ES7134-6HD01-0BA1 delivers the precision, flexibility, and reliability required for accurate analog signal output in modern distributed automation systems.
