6ES7155-5AA00-0AC0 | Siemens | I/O Module
- Regular price
- $799.00
- Sale price
- $799.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 6ES7155-5AA00-0AC0
Description
The Siemens 6ES7155-5AA00-0AC0 SIMATIC ET200MP IM155-5 PN HF Profinet I/O Module is an interface module designed for the SIMATIC ET 200MP system. It enables the connection of up to 12 I/O modules without requiring additional power supplies. With additional power supplies, it can accommodate up to 30 I/O modules. The module supports features such as Shared Device, MRP, IRT (Isochronous Real-Time) with a minimum time of 0.25ms, Isochronicity FW-Update, and I&M0...3. It also includes Fast Startup S2 Redundancy and shared device functionality with four controllers. This module facilitates efficient and reliable I/O communication within the system.
Technical Specifications
Specifications
|
Part # |
6ES7155-5AA00-0AC0 |
|
Manufacturer |
SIEMENS |
|
Category |
PLCs/Machine Control |
|
Subcategory |
VDC Logic I/O Module |
|
Product type designation |
IM 155-5 PN HF |
|
HW functional status |
FS03 |
|
Firmware version |
V4.4 |
|
FW update possible |
Yes |
|
Vendor identification (VendorID) |
002AH |
|
Device identifier (DeviceID) |
0X0312 |
|
Product function |
I&M data Yes; I&M0 to I&M3 |
|
Module swapping |
Yes; In combination with active backplane bus |
|
Isochronous mode |
Yes |
|
Engineering with |
STEP 7 TIA Portal configurable/integrated as of version V16 with HSP 308; STEP 7 configurable/integrated as of version V5.5 SP3 / -; PROFINET as of GSD version/GSD revision V2.3 / - |
|
Configuration control |
via user data No; via dataset Yes |
|
Supply voltage |
Rated value (DC) 24 V; permissible range, lower limit (DC) 20.4 V; permissible range, upper limit (DC) 28.8 V |
|
Reverse polarity protection |
Yes |
|
Short-circuit protection |
Yes |
Information About 6ES7155-5AA00-0AC0
The Siemens 6ES7155-5AA00-0AC0 is a SIMATIC ET 200MP IM155-5 PN HF Profinet I/O Interface Module designed for seamless integration within industrial automation systems. This module, part of the SIEMENS 6ES7 series, plays a critical role in facilitating the connection of up to 12 I/O modules without requiring an additional power supply. Furthermore, when additional power supply is employed, this module can support connectivity with up to 30 I/O modules.
The module operates as a shared device, implementing Multiple Redundancy Protocol (MRP) and Isochronous Real-Time (IRT) functionality with a minimum cycle time of >=0.25ms. These features contribute to the module's ability to ensure precise and synchronized data exchange within the Profinet network.
The firmware of the 6ES7155-5AA00-0AC0 module is upgradeable, allowing users to benefit from future enhancements and improvements. The firmware update can be performed efficiently, ensuring the module remains up-to-date with the latest features and optimizations.
The module supports Information and Maintenance (I&M) data from 0 to 3, providing valuable information for diagnostics and maintenance purposes. Additionally, it enables hot-swapping functionality, allowing modules to be replaced or added during operation, in combination with an active backplane bus.
For engineering purposes, the module is configurable and integrable using the STEP 7 TIA Portal, starting from version V16 with HSP 308. It is also compatible with STEP 7, starting from version V5.5 SP3. The PROFINET functionality is supported from GSD version/GSD revision V2.3 onwards.
Configuration control can be achieved both via user data and dataset, offering flexibility in adapting the module to specific application requirements.
The module operates with a supply voltage of 24 V, with permissible ranges between 20.4 V (lower limit) and 28.8 V (upper limit). It incorporates reverse polarity protection and short-circuit protection, ensuring the integrity of the module and connected devices.
Manufacturer information
Siemens: A renowned global manufacturer, leading in technology, engineering, and innovation across diverse sectors for a sustainable future.
