6ES7215-1HG40-0XB0 | Siemens | CPU

Description

Technical Specifications

Specifications

Information About 6ES7215-1HG40-0XB0

The 6ES7215-1HG40-0XB0, manufactured by Siemens, belongs to the SIMATIC S7-1200 series and is specifically designated as the CPU 1215C model. As a compact central processing unit (CPU), it is equipped with a DC/DC/relay configuration, featuring 2 PROFINET ports for communication purposes.

The onboard input/output (I/O) specifications encompass 14 digital inputs (DI) operating at 24 V DC, 10 digital outputs (DO) with relay functionality and a capacity of 2 A. Additionally, the unit incorporates 2 analog inputs (AI) supporting a voltage range of 0-10 V DC, and 2 analog outputs (AO) with a current range of 0-20 mA DC.

The power supply requirements for the 6ES7215-1HG40-0XB0 entail a direct current (DC) input ranging from 20.4 V to 28.8 V DC. The unit's program and data memory has a capacity of 200 KB, facilitating storage and retrieval of essential data for seamless operational functionality.

As a part of the SIMATIC S7-1200 series, the CPU 1215C model adheres to Siemens' high standards for industrial automation. The compact design and versatile features make it suitable for diverse applications where efficient and reliable control systems are paramount. The inclusion of PROFINET ports enhances communication capabilities, enabling seamless integration into industrial networks.

The digital inputs and outputs cater to a range of industrial automation scenarios, providing flexibility and adaptability. The analog inputs and outputs further extend the unit's utility, accommodating systems that require precise analog signal processing.
