6ES7331-7NF00-0AB0 | Siemens S7-300 SM331 8-Channel Analog Voltage/Current Input Module
- Regular price
- $549.00
- Sale price
- $549.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 6ES7331-7NF00-0AB0
Description
The Siemens 6ES7331-7NF00-0AB0 is an SM331 analog input module for the SIMATIC S7-300 platform, offering eight channels for voltage and current measurement. It supports multiple input ranges with 16-bit resolution and parameterizable integration times. The module provides optical isolation to improve signal integrity and protect control systems from electrical interference.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | PLCs/Machine Control |
| Part Number | 6ES7331-7NF00-0AB0 |
| Subcategory | PLC Module/Rack |
| Series | SIMATIC S7-300 |
| Type | Optically Isolated Analog Input Module |
| Number of Inputs | 8 |
| Input Types | Voltage / Current |
| Supported Input Ranges | ±10 V, ±5 V, 1–5 V, ±20 mA, 0/4–20 mA |
| Resolution | 16-bit |
| Accuracy | Voltage: ±0.1–0.7% • Current: ±0.3–0.9% • Resistance: ±0.7% |
| Integration Time | 10 / 16.67 / 20 / 100 ms (parameterizable) |
| Common Point | 50 V common |
| Voltage Rating | 5 VDC |
| Amperage Rating | 130 mA |
| Isolation | Optical isolation per channel |
| Connector | 40-pin front connection |
| Dimensions (H × W × D) | 125 × 40 × 117 mm |
| Mounting | S7-300 rack mount |
Information About 6ES7331-7NF00-0AB0
The 6ES7331-7NF00-0AB0 is part of the SIMATIC S7-300 SM331 family, designed for precise analog data acquisition in modular PLC systems. Its eight optically isolated analog inputs accept a wide range of industry-standard signals such as ±10 V, ±5 V, 1–5 V, ±20 mA, and 0/4–20 mA, making it suitable for diverse instrumentation. The module features adjustable integration times—10, 16.67, 20, or 100 ms—allowing users to balance noise immunity and response speed. Typical applications include process monitoring, current-loop measurement, and interfacing with analog sensors in automated systems requiring stable, high-resolution data.
Key Features:
- Eight analog inputs: Supports voltage and current ranges for flexible signal acquisition.
- 16-bit resolution: Ensures accurate and detailed measurement of analog values.
- Optical isolation: Improves signal quality and protects modules from electrical disturbances.
- Multiple input ranges: Accepts ±10 V, ±5 V, 1–5 V, ±20 mA, 0/4–20 mA signals.
- Configurable integration time: Selectable 10, 16.67, 20, or 100 ms filtering.
- High measurement accuracy: Voltage, current, and resistance accuracy ratings suitable for industrial use.
- Compact S7-300 form factor: 125 × 40 × 117 mm for efficient cabinet installation.
- Reliable performance: Designed for stable analog processing in demanding automation environments.
The 6ES7331-7NF00-0AB0 delivers the reliability and precision required for high-accuracy analog signal acquisition in SIMATIC S7-300 control systems.
