6ES7534-7QE00-0AB0 | Siemens Analog Input/Output Module

Description

The 6ES7534-7QE00-0AB0 Siemens SIMATIC S7-1500 Analog input/output module is designed to facilitate precise control and monitoring within industrial automation systems. This module offers AI 4x U/I/R/RTD/TC ST functionality, providing four channels in groups of four for various analog input configurations including voltage, current, resistance, RTD, and thermocouple measurements. Additionally, it features AQ 2x U/I ST with two channels in groups of two for analog output tasks, along with the provision of hardware interrupts for enhanced system responsiveness.

The module incorporates diagnostics capabilities to ensure optimal performance and reliability. It includes features such as substitute value and common mode voltage of approximately 10 V, contributing to accurate and stable operation. With a 16-bit resolution and an accuracy of 0.3%, it offers precise measurement and control capabilities suitable for diverse industrial applications.

Technical Specifications

Information About 6ES7534-7QE00-0AB0

The 6ES7534-7QE00-0AB0 Siemens SIMATIC S7-1500 Analog input/output module is engineered to facilitate precise analog signal processing and control within industrial automation systems. This module features AI 4x U/I/R/RTD/TC ST functionality, providing four channels organized in groups of four for diverse analog input configurations, including voltage (U), current (I), resistance (R), resistance temperature detectors (RTD), and thermocouples (TC).

Additionally, the module incorporates AQ 2x U/I ST capabilities, offering two channels organized in groups of two for analog output tasks. The inclusion of hardware interrupts enhances system responsiveness by allowing the module to prioritize critical control signals efficiently.

Moreover, the module is equipped with diagnostics functionalities to ensure optimal performance and reliability. It includes features such as substitute value provision, which enables the module to maintain operation by substituting values in case of signal discrepancies or failures. The common mode voltage is approximately 10 volts, ensuring compatibility and stability in various operating conditions.

With a 16-bit resolution and an accuracy of 0.3%, the module delivers precise measurement and control capabilities necessary for demanding industrial applications requiring high levels of precision. This accuracy level ensures that the module effectively captures and processes analog signals with minimal error margins.

Furthermore, the module comes with essential accessories to facilitate installation and integration into existing automation systems. These accessories include a push-in front connector, infeed element, shield bracket, and shield terminal, ensuring convenient setup and reliable operation.
