6KG1143003X4B1 | General Electric 3HP 460V AC Drive with Keypad
- Regular price
- $1,867.00
- Sale price
- $1,867.00
- Regular price
-
Couldn't load pickup availability
Do you need more quantity?
Product Description P/N: 6KG1143003X4B1
Description
The 6KG1143003X4B1 is a 3HP 460VAC Phase-3 Drive from the GE Fuji AF-300 G11 series. This drive is no longer receiving support from GE because it is a legacy series.
Technical Specifications
| Brand | General Electric |
| Category | Drives |
| Part Number | 6KG1143003X4B1 |
| Subcategory | Drive |
| Series | AF-300 G11 |
| Product Type | AC Drive with Keypad |
Information About 6KG1143003X4B1
The 6KG1143003X4B1 has a rated output current of 5.5 amps and an 8.3-amp overload that can reach 150% for 1 minute. It is 10.24” tall, 5.91” wide, and 5.71” deep and weighs 8.4 lbs. The efficiency of the drive when it is at 2 kHz is 97% and loses 80 watts of power. When it is functioning at 15 kHz, it has an efficiency of 94.5% and loses 150 watts of power. It should be stored in an atmosphere that has a relative humidity between 5 to 95% and should be at a temperature ranging from -10° to +50° Celsius.
The 6KG1143003X4B1 is a rectangular drive. It has a keypad panel that is used as the main user interface for this drive. It has a 7-segment 4-digit LED display and an LCD display. It has 9 keys on the keypad that are labeled stop, FWD, REV, the up arrow, the down arrow, shift>>, reset, and PRG. The 6KG1143003X4B1 is protected by a NEMA 4 type enclosure that should be kept in an inside location. It should be kept away from all corrosive and combustible materials. This drive should never be operated from the floor. It should be mounted vertically to a metallic surface. Do not mount this device horizontally or directly next to another device.
Manufacturer information
General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions.
IQElectro 2 Year Warranty
IQElectro offers a 2-Year Warranty on all our products. This complimentary two-year warranty ensures that every purchase from IQElectro is a secure investment in the future of your company.Warranty Terms and Conditions
IQElectro is not an authorized distributor.
