6SL3055-0AA00-5BA3 | SIEMENS SINAMICS S120 SMC20 Encoder Sensor Module, DRIVE-CLiQ, 24 V DC
- Regular price
- $294.00
- Sale price
- $294.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 6SL3055-0AA00-5BA3
Description
The Siemens 6SL3055-0AA00-5BA3 is an SMC20 sensor module for the SINAMICS S120 drive system, used for evaluating incremental and absolute encoder signals. It provides a dedicated encoder interface and a DRIVE-CLiQ connection for seamless communication with the control unit. Operating on 24 V DC, the module supports precise feedback acquisition for high-performance motor control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | SIEMENS |
| Category | Drives |
| Part Number | 6SL3055-0AA00-5BA3 |
| Subcategory | Drive |
| Type | S120 |
| Series | SMC20 |
| Main Function | Encoder sensor evaluation module |
| Mounting Type | Cabinet-mounted |
| Dimensions | 150 mm (H) × 30 mm (W) × 111 mm (D) |
| Supply Voltage | 24 V DC |
| Encoder Interface | SIN/COS 1 Vpp, EnDat 2.1, SSI (X520) |
| Communication Interface | DRIVE-CLiQ (to control unit) |
| Connection Type | M4 screw connection (PE) |
| Technical Compatibility | SINAMICS S120 drive systems |
| Module Width | 30 mm |
| Application | Motor feedback acquisition and processing |
| Installation | Cabinet-mounted drive assemblies |
Information About 6SL3055-0AA00-5BA3
The 6SL3055-0AA00-5BA3 is part of the SINAMICS S120 SMC20 family, designed specifically for capturing and processing encoder data within cabinet-mounted drive configurations. Its construction enables connection to incremental encoders with SIN/COS 1 Vpp signals as well as absolute encoders using EnDat 2.1 or SSI protocols, providing flexibility across a range of motor feedback systems. The module integrates directly with SINAMICS S120 drives through a DRIVE-CLiQ interface, ensuring synchronized communication and accurate system diagnostics. Typical applications include servo systems, precision positioning tasks, and high-performance drive setups requiring stable and reliable encoder feedback.
Key Features:
- Encoder compatibility: Supports SIN/COS 1 Vpp incremental encoders and EnDat 2.1/SSI absolute encoders.
- DRIVE-CLiQ interface: Provides direct communication to SINAMICS S120 control units.
- Cabinet-mounted design: Slim 30 mm width allows dense installation in control enclosures.
- Robust signal evaluation: Ensures precise encoder feedback for advanced motor control.
- Flexible wiring: Includes M4 screw terminal for protective earth connection.
- System integration: Fully compatible with SINAMICS S120 drives.
- Reliable construction: Designed for industrial environments requiring stable encoder interfacing.
- Compact form factor: 150 × 30 × 111 mm for efficient panel layout.
The 6SL3055-0AA00-5BA3 delivers the reliability and precision required for high-performance encoder feedback in SINAMICS S120 drive systems.
