700-FSH3VU23 | Allen-Bradley General Purpose High Performance Timing Relay
- Regular price
- $107.00
- Sale price
- $107.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 700-FSH3VU23
Description
The 700-FSH3VU23 is a high-performance timing relay from Allen-Bradley designed for general-purpose timing applications with selectable flasher functions. It offers wide voltage flexibility and precise time range settings to control cyclic operations in automation systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Controls & Indicators
|
| Part Number | 700-FSH3VU23 |
| Subcategory | Time Delay Relay |
| Function | Flasher (Repeat Cycle Start with Pulse or Pause) |
| Voltage Range | 24–48 VDC / 24–240 VAC (50/60 Hz) |
| Control Voltage | 24–240 V |
| Timing Range | 0.05 seconds – 60 hours |
| Contact Configuration | 1 Changeover Contact (SPDT) |
| Mounting Type | Front, DIN Rail |
| Standard Certifications | CCC, CE, cUL, MARINE, UL |
| Weight | 0.2600 lb |
Information About 700-FSH3VU23
The 700-FSH3VU23 is a high-performance general-purpose timing relay manufactured by Allen-Bradley, specifically designed for repetitive cyclic start-stop applications with pulse or pause control. The relay supports a broad control voltage range of 24–240V AC and 24–48V DC, enabling integration into diverse power environments. It features a single changeover contact (SPDT) for flexible switching and is front/DIN rail mountable for ease of panel installation. With selectable timing ranges from 0.05 seconds to 60 hours across two separate scales, this unit ensures highly adaptable timing control in industrial automation.
Key Features:
- Flasher Function (Repeat Cycle with Pulse or Pause Start): Supports cyclic operation with selectable start using either a pulse or a pause, ideal for use in signaling or lighting systems.
- Wide Timing Range: Dual time ranges allow adjustable timing from 0.05 seconds up to 60 hours, providing flexibility for both short-duration and long-term control needs.
- Flexible Control Voltage: Operates across a broad input range of 24–48 VDC and 24–240 VAC at 50/60 Hz, making it adaptable for various electrical environments.
- SPDT Contact Configuration: Includes one single-pole double-throw (SPDT) changeover contact, suitable for switching between two circuits or control paths.
- Easy Mounting Options: Designed for front-panel or DIN rail mounting, simplifying installation within control panels or enclosures.
- Rugged Industrial Design: Built to withstand harsh operating conditions such as vibration and temperature variation, ensuring long-term durability.
- Standards Compliance: Certified under CCC, CE, UL, CUL, and Marine approvals, making it suitable for global use in diverse industrial sectors.
The 700-FSH3VU23 provides robust functionality and timing precision for demanding industrial automation environments.
