Part #: 700-HK32Z24-4 Manufactured by: Allen-Bradley
$72.00
$72.00
1 in Stock
Condition: New – Open box
Shipping calculated at checkout.
Product Overview
700-HK General Purpose Slim Line Relay, 8 Amp Contact, DPDT, 24V DC, Pilot Light
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa
Contact Us!

Talk to a real expert.

phone
+1 (828) 222-3490
email
sales@iqelectro.com
Mon–Sat, 7:00 AM – 12:00 PM (EST)
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 700-HK32Z24-4
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 700-HK32Z24-4

Description / Specifications

Description

The Allen-Bradley 700-HK32Z24-4 is a general-purpose slim line relay designed for compact, high-reliability industrial control applications. Operating on 24V DC and featuring 2 changeover (DPDT) 8A contacts, this relay provides dependable switching performance in automation panels and control systems. Its integrated pilot light offers clear visual indication of coil status, enhancing maintenance and troubleshooting efficiency.





Technical Specifications

Condition New / Never Used Surplus
Brand Allen-Bradley
Series 700-HK
Part Number 700-HK32Z24-4
Category Panel Accessories
Subcategory Relay / Socket
Type Slim Line “Ice Cube” Relay, 8-Blade
Coil Voltage 24V DC
Contact Configuration DPDT (2 Changeover)
Contact Rating 8A
Poles 2
Mounting Style Socket
Pilot Light Yes
Applications General-purpose industrial control





Information About 700-HK32Z24-4

The Allen-Bradley 700-HK32Z24-4 belongs to the 700-HK slim relay family, engineered for efficient use of panel space while delivering industrial-grade performance. With DPDT standard contacts, this relay supports versatile control functions, including sequencing, interlocking, signal switching, and general control logic within automation environments. Powered by a 24V DC control voltage, the coil ensures reliable actuation with consistent response time. The relay’s 8-blade, ice-cube style design is compatible with standard relay sockets, enabling quick installation and replacement without wiring changes. Designed to handle up to 8 amps, this relay is suitable for a wide range of loads, from pilot circuits to moderate power devices. Its slim profile allows greater density in panel layouts, making it ideal for modern, space-optimized control cabinets. The relay includes an integrated pilot light indicator, providing immediate visual confirmation of relay coil energization—an essential feature for diagnostics during commissioning or troubleshooting.

Key Features:

  • Slim line design for compact panel integration
  • 24V DC coil voltage
  • DPDT contact configuration (2 changeover contacts)
  • 8A contact rating
  • Ice cube, 8-blade relay format
  • Integrated pilot light for coil status indication
  • Socket-mount installation
  • Suitable for general-purpose industrial control

Allen-Bradley’s proven durability and performance ensure long service life, making the 700-HK32Z24-4 a dependable choice for OEMs, system integrators, and maintenance technicians in industrial automation.
