700-HLS1Z24 | Allen-Bradley Solid State Relay Output, 1 N.O. SSR, 24V DC Coil

The Allen-Bradley 700-HLS1Z24 is designed for solid-state output in control systems. It acts as an interface between low-voltage signals and power devices, ensuring reliable switching. Its solid-state contact offers fast response and longer service life than mechanical relays. This makes it ideal for automation systems that require precision and durability.

The 700-HLS1Z24 relay measures 88 mm in width, 6.2 mm in depth, and 76 mm in height. Its slim 6.2 mm profile makes it particularly well-suited for high-density installations where panel space is limited. Despite the compact form, it provides reliable and durable performance in demanding applications. The standardized size allows easy integration into DIN rail systems alongside other control components. This design helps reduce the overall cabinet footprint without sacrificing functionality. It’s ideal for OEMs and systems integrators aiming for compact layouts.

This relay operates with a coil voltage of 24 VDC and supports an output load current of up to 2 Amps. These electrical ratings are ideal for controlling small to medium DC-powered loads such as solenoids, sensors, and indicator lights. The 24V rating aligns well with common industrial control systems, ensuring compatibility and safety. The 2 Amp limit provides enough capacity for most standard interface applications. It’s important not to exceed these ratings to avoid thermal issues or performance degradation. Proper load matching extends the relay’s operational life.

Yes, the 700-HLS1Z24 is designed to perform well in vibration-prone environments. When combined with the spring-clamp terminal base, it ensures secure connections even under constant mechanical stress. The solid-state internal structure has no moving parts, which eliminates contact bounce and enhances reliability in dynamic conditions. It’s well-suited for use in mobile machinery, marine systems, and factory floors with high mechanical impact. This makes it a durable solution for installations where traditional relays may fail prematurely. It also reduces maintenance needs over time.

Yes, the 700-HLS1Z24 is still in active production and supported by Allen-Bradley. It belongs to their current line of terminal block relays designed for compact, high-performance applications. Users can purchase it through official Rockwell Automation distributors or authorized resellers. However, since product availability can vary by region or lifecycle phase, it’s advisable to verify with suppliers for ongoing projects. If the part is ever discontinued, Allen-Bradley typically offers migration paths or drop-in replacements within the same family. This helps maintain system continuity with minimal changes.
