750-306 | Wago DeviceNet Fieldbus Coupler for WAGO I/O System 750
- Regular price
- $489.00
- Sale price
- $489.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 750-306
Description
The Wago 750-306 is a DeviceNet fieldbus coupler designed to connect the WAGO I/O System as a client device within DeviceNet automation networks. It manages cyclic data exchange between distributed I/O modules and the control system, supporting both analog and digital signal types. This coupler is intended for industrial applications requiring reliable DeviceNet communication and modular I/O expansion.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Wago |
| Category | Industrial Automation |
| Part Number | 750-306 |
| Subcategory | Fieldbus Couplers |
| Fieldbus Protocol | DeviceNet |
| Max. Fieldbus Nodes | 64 |
| Max. I/O Points | 6000 |
| Transmission Rate | 125 / 250 / 500 kBd |
| Max. Process Image | 512 bytes input / 512 bytes output |
| Max. Modules per Node | 64 |
| System Supply Voltage | 24 VDC (-25 … +30 %) |
| Field Supply Voltage | 24 VDC (-25 … +30 %) |
| Current Consumption (5 V System) | 350 mA |
| Electrical Isolation | 500 V system/field |
| Degree of Protection | IP20 |
| Mounting | DIN-35 rail |
| Operating Temperature | 0 to +55 °C |
| Weight | 200 g |
Information About 750-306
The 750-306 is part of the WAGO I/O System 750 fieldbus coupler series and is engineered specifically for DeviceNet fieldbus integration. It automatically detects all connected I/O modules and creates a structured local process image that includes analog, digital, and specialty module data. Analog and specialty data are transferred using words or bytes, while digital signals are packed bit by bit and aligned byte-wise as needed. Designed for DIN-rail mounting, the coupler provides integrated power distribution, electrical isolation, and ODVA-certified DeviceNet communication for industrial control systems.
Key Features:
- DeviceNet Fieldbus Interface: Connects the WAGO I/O System as a client device in DeviceNet networks.
- Automatic Process Image Creation: Detects installed modules and builds a local process image automatically.
- Mixed Signal Support: Handles analog, digital, and specialty I/O data within a single node.
- Flexible Data Mapping: Transfers analog data as words or bytes and digital data bit by bit with automatic byte alignment.
- High I/O Capacity: Supports up to 6000 I/O points for scalable automation solutions.
- Multiple DeviceNet Messaging Types: Supports polled, strobed, cyclic, and change-of-state messaging.
- Integrated Power Distribution: Supplies system and field power via internal power jumper contacts.
- Electrical Isolation: Provides 500 V isolation between system and field supplies for operational safety.
- ODVA Certified: Complies with DeviceNet standards for interoperability and network reliability.
The 750-306 delivers the reliability and precision required for DeviceNet-based distributed I/O and industrial automation systems.
