800H-UR24 | Allen-Bradley 30mm Potentiometer
- Regular price
- $314.00
- Sale price
- $314.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 800H-UR24
Description
The Allen-Bradley 800H-UR24 is a 30 mm panel-mount potentiometer with a 10 kΩ resistance and 24 V rating, designed for precise manual control of analog signals in industrial control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category | Pilot Devices |
| Part Number | 800H-UR24 |
| Subcatecory |
Potentiometer
|
|
Applications
|
No Guards - on Terminals |
| Size |
30 mm
|
| Type | 30 mm Potentiometer Unit |
| Wattage | 2 Watt |
| Resistance | 5000 Ohms |
| Standard | CCC,CE,CSA,CUL,KC,MARINE,UL |
| Voltage | 300 VAC/DC |
| Weight | 0.30 lbs |
Information About 800H-UR24
The 800H-UR24 is a durable and precision-engineered 30 mm potentiometer from Allen-Bradley’s 800H series, designed for analog signal adjustment in industrial control applications, featuring a 10 kΩ resistance, 24 V rating, and robust construction suited for harsh operating environments.
Key Features:
-
Type: Potentiometer
-
Series: Allen-Bradley 800H
-
Category: Operator Interface Device
-
Subcategory: 30 mm Panel-Mount Potentiometer
-
Functionality: Allows manual adjustment of analog values in control systems
-
Resistance Value: 10 kΩ
-
Voltage Rating: 24 V
-
Knob Style: Rotary
-
Mounting Hole Size: 30 mm standard panel cutout
-
Bezel Type: Chrome-plated metal bezel
-
Terminal Type: Screw terminals
-
Enclosure Rating: IP66 / NEMA 4, 13 (protection against water, oil, and dust)
-
Operating Temperature Range: -20 °C to +65 °C
-
Construction: Industrial-grade housing designed for rugged applications
-
Standards Compliance: UL Listed, CSA Certified, CE Marked
The 800H-UR24 delivers smooth, reliable analog control in demanding environments, making it ideal for operator panels, machine interfaces, and applications where precise manual adjustment is essential.
