821-0087-2R | Cognex Barcode Scanner Hand Held
- Regular price
- $999.00
- Sale price
- $999.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 821-0087-2R
Description
The Cognex 821-0087-2R is a compact, high-performance barcode scanner engineered for reliable decoding of both 1D and 2D symbologies. It offers robust scanning capability with advanced image acquisition, making it ideal for use in industrial automation and logistics environments.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cognex |
| Category |
Bar Code Equipment
|
| Part Number | 821-0087-2R |
| Subcategory | Bar Code Scanner Hand Held |
| Series | DataMan DM300x |
| Image Sensor | 1/1.8-inch CMOS |
| Image Resolution | 800 x 600 pixels |
| Pixel Size | 5.3 µm square |
| Shutter Speed | 5 µs to 100,000 µs |
| Frame Rate | 60 fps |
| Supported Codes | 1D (Codabar, Code 39, etc.), 2D (QR, Data Matrix, Aztec) |
| LED Lighting | Red LED, IEC62471 Low Risk |
| Power Supply | 24V DC ±10% |
| Interfaces | RS-232 and Ethernet |
| Operating Temperature | 0°C to 45°C |
| Protection Rating | IP65 (with cables and cover) |
| Mounting | M4 threaded holes |
| Weight | 0.99 lbs |
Information About 821-0087-2R
The 821-0087-2R is part of the DataMan DM300x series from Cognex, equipped with a 1/1.8-inch CMOS sensor and a resolution of 800x600 pixels. Designed for high-speed applications, it delivers up to 60 frames per second and supports electronic shutter speeds from 5 µs to 100,000 µs. The device supports both RS-232 and Ethernet interfaces, ensuring flexible integration into existing systems. Its IP65-rated enclosure, coupled with LED lighting and support for a wide range of code formats, allows it to operate efficiently in demanding industrial settings.
Key Features:
- CMOS Image Sensor: Captures high-quality images using a 1/1.8-inch sensor with 800x600 resolution.
- Fast Frame Rate: Operates at up to 60 frames per second for rapid barcode decoding.
- Wide Code Support: Reads 1D codes like Codabar and Code 39, and 2D codes including QR, Data Matrix, and Aztec.
- Industrial Protection: IP65-rated enclosure ensures resistance to dust and water with proper cable and cover assembly.
- Flexible Shutter Speed: Electronic shutter configurable between 5 µs and 100,000 µs to adapt to various lighting conditions.
- Reliable Lighting: Integrated red LED illumination classified as low risk under IEC62471 standards.
- Versatile Interfaces: Equipped with both RS-232 and Ethernet ports for communication flexibility.
- Compact and Lightweight: Weighs only 165 g, with M4 threaded holes for straightforward mounting.
The 821-0087-2R delivers the reliability and precision required for automated barcode scanning in tough industrial environments.
