8536SBO2V06 | Schneider Electric NEMA Motor Starter
8536SBO2V06 | Schneider Electric NEMA Motor Starter
Part #: 8536SBO2V06 Manufactured by: Schneider Electric

8536SBO2V06 | Schneider Electric NEMA Motor Starter

Regular price
$417.00
Sale price
$417.00
Regular price
Never Used Surplus
4 in Stock
Shipping calculated at checkout.
Product Overview
The 8536SBO2V06 is a NEMA motor starter of Type S, primarily utilized for full voltage starting and stopping of AC squirre...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
IQElectro LLC BBB Business Review
warranty
Product comes with IQElectro 2-Year Warranty
Warranty for item #: 8536SBO2V06
IQElectro offers a complimentary 2-year warranty on all our products. This ensures that every purchase you make from IQElectro is a reliable and trustworthy investment for the future of your company. Warranty Terms
IQElectro is NOT an authorized distributor for Schneider Electric
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.
8536SBO2V06 | Schneider Electric NEMA Motor Starter
    8536SBO2V06 | Schneider Electric NEMA Motor Starter
8536SBO2V06 | Schneider Electric NEMA Motor Starter
Return/Exchange within 30-Days.
If any product is damaged upon delivery, you may request an Exchange or Refund within 30 days of receiving your order.
2-3 Day Free Shipping
IQElectro provides free shipping within 2-3 days from the moment the order is placed on our website.

Product Description P/N: 8536SBO2V06

Description / Specifications

Description

The 8536SBO2V06 is a NEMA Type S motor starter designed for full voltage starting and stopping of AC squirrel cage motors. It belongs to Size 0 and operates at 480VAC. This non-reversing starter has a 3-phase, 3-pole configuration with an 18A rating. NEMA Size 0 starters support motor ratings up to 5 HP at 460VAC. Equipped with a melting alloy type overload relay, it utilizes Type B thermal units to detect overcurrent conditions.



Technical Specifications

Part #

8536SBO2V06

Category

Contactors & Starters

Subcategory

Starter

NEMA Size

0

Rated Current

18 A

Number of Poles

3P

Maximum Voltage Rating

600 V AC

Phase

3 phase

Type of Overload

Melting alloy

Short Circuit Current Rating (SCCR)

Circuit-breaker: 5 kA at 600 V AC, Fuse: 5 kA at 600 V AC

Coil Voltage

440 V AC 50 Hz, 480 V AC 60 Hz

Control Circuit Type

Common control circuit

Control Units

No control units

Pilot Light

Without pilot light

Auxiliary Contacts

Without

Terminal Type

Screw clamp terminals

Height

6.81 in (172.96 mm)

Width

3.50 in (88.90 mm)

Depth

4.22 in (107.19 mm)



Information About 8536SBO2V06

The 8536SBO2V06 is a NEMA motor starter belonging to the Type S category, designed specifically for the full voltage starting and stopping of AC squirrel cage motors. These starters, under the Type S classification, can handle ratings of up to 810 amperes.

This particular motor starter is a 3 pole NEMA Size 0 non-reversing starter with an 18 ampere rating. NEMA Size 0 motor starters are suitable for 3 phase applications, providing ratings of 3 HP at 200 and 230 VAC and 5 HP at 460 and 575 VAC.

Featuring a melting alloy type overload relay, this starter utilizes Type B thermal units to detect over current conditions effectively. With a maximum Short Circuit Current Rating (SCCR) of 5 kA at 600 V AC, as per UL508A standards, it ensures robust protection when paired with an appropriate circuit breaker or fuse.





Manufacturer information

Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.

Warrany image

IQElectro 2 Year Warranty

IQElectro offers a 2-Year Warranty on all our products. This complimentary two-year warranty ensures that every purchase from IQElectro is a secure investment in the future of your company.
Warranty Terms
warningIQElectro is not an authorized distributor.
IQElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses. Some hardware products may contain software and firmware and may not be legally operated without first obtaining an appropriate license from the manufacturer. IQElectro makes no representation as to whether a product will or will not have software or firmware and, if it does, whether the software or firmware is the revision level that you need for your application. IQElectro also makes no representations as to your ability or right to download or otherwise obtain software or firmware for the product from the Original Manufacturer, its distributors, or any other source. IQElectro also makes no representations as to your right to install any such software or firmware on the product. IQElectro will not obtain or supply software or firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing software or firmware. Customer acknowledges and agrees that IQElectro DOES NOT provide any software, firmware, operating system, or right-to-use licenses with the products it sells. Customers understand and agree that proper software (firmware) licensing, maintenance, and upgrades are subject to the applicable manufacturer's Licensing Agreement or similar document. Disclaimer Policy.
Description / Specifications

Description

The 8536SBO2V06 is a NEMA Type S motor starter designed for full voltage starting and stopping of AC squirrel cage motors. It belongs to Size 0 and operates at 480VAC. This non-reversing starter has a 3-phase, 3-pole configuration with an 18A rating. NEMA Size 0 starters support motor ratings up to 5 HP at 460VAC. Equipped with a melting alloy type overload relay, it utilizes Type B thermal units to detect overcurrent conditions.



Technical Specifications

Part #

8536SBO2V06

Category

Contactors & Starters

Subcategory

Starter

NEMA Size

0

Rated Current

18 A

Number of Poles

3P

Maximum Voltage Rating

600 V AC

Phase

3 phase

Type of Overload

Melting alloy

Short Circuit Current Rating (SCCR)

Circuit-breaker: 5 kA at 600 V AC, Fuse: 5 kA at 600 V AC

Coil Voltage

440 V AC 50 Hz, 480 V AC 60 Hz

Control Circuit Type

Common control circuit

Control Units

No control units

Pilot Light

Without pilot light

Auxiliary Contacts

Without

Terminal Type

Screw clamp terminals

Height

6.81 in (172.96 mm)

Width

3.50 in (88.90 mm)

Depth

4.22 in (107.19 mm)



Information About 8536SBO2V06

The 8536SBO2V06 is a NEMA motor starter belonging to the Type S category, designed specifically for the full voltage starting and stopping of AC squirrel cage motors. These starters, under the Type S classification, can handle ratings of up to 810 amperes.

This particular motor starter is a 3 pole NEMA Size 0 non-reversing starter with an 18 ampere rating. NEMA Size 0 motor starters are suitable for 3 phase applications, providing ratings of 3 HP at 200 and 230 VAC and 5 HP at 460 and 575 VAC.

Featuring a melting alloy type overload relay, this starter utilizes Type B thermal units to detect over current conditions effectively. With a maximum Short Circuit Current Rating (SCCR) of 5 kA at 600 V AC, as per UL508A standards, it ensures robust protection when paired with an appropriate circuit breaker or fuse.





Manufacturer information

Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
