8536SDG1V03 | Schneider Electric NEMA Size 2 Nonreversing Motor Starter 45A
- Regular price
- $2,499.00
- Sale price
- $2,499.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 8536SDG1V03
Description
The Schneider Electric 8536SDG1V03 is a nonreversing enclosed NEMA motor starter designed to control and protect three-phase induction motors in industrial applications. It features a NEMA Size 2 configuration with a 45 amp rating and is suitable for motors up to 25 HP depending on operating voltage. This starter is commonly used in machinery, pumps, and conveyors where dependable motor starting and overload protection are required.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | Contactors & Starters |
| Part Number | 8536SDG1V03 |
| Subcategory | Starter |
| Starter Type | Nonreversing motor starter |
| NEMA Size | Size 2 |
| Current Rating | 45 A |
| Control Coil Voltage | 220 VAC @ 50 Hz / 240 VAC @ 60 Hz |
| Motor Phase | Three-phase |
| Motor HP @ 200 VAC | 10 HP |
| Motor HP @ 230 VAC | 15 HP |
| Motor HP @ 460 VAC | 25 HP |
| Motor HP @ 575 VAC | 25 HP |
| Enclosure Type | NEMA 1 |
| Application Use | Industrial motor control |
| Weight | 13.00 lbs |
Information About 8536SDG1V03
The 8536SDG1V03 is part of the Schneider Electric 8536 S series of NEMA-rated motor starters, known for rugged construction and long service life. It is built as a nonreversing starter housed in a NEMA 1 enclosure for indoor industrial environments. The unit includes a contactor and overload relay assembly designed to coordinate motor starting and protection functions. It operates with a dual-rated coil voltage, supporting 220 VAC at 50 Hz and 240 VAC at 60 Hz, making it compatible with common industrial control power systems.
Key Features:
- Nonreversing Motor Starter: Designed for straightforward motor start and stop control without direction reversal.
- NEMA Size 2 Construction: Supports medium-duty motor control applications.
- 45 Amp Rating: Suitable for motors requiring higher current capacity.
- Wide Motor Horsepower Support: Rated up to 10 HP at 200 VAC, 15 HP at 230 VAC, and 25 HP at 460/575 VAC.
- Dual Coil Voltage: Operates at 220 VAC (50 Hz) or 240 VAC (60 Hz) control power.
- Enclosed Design: Supplied in a NEMA 1 enclosure for protection in indoor environments.
- Three-Phase Operation: Designed for three-phase motor control systems.
The 8536SDG1V03 delivers the reliability and precision required for industrial motor starting and protection applications.
