Part #: 9007C62B2 Manufactured by: Schneider Electric
Regular price
$229.00
Sale price
$229.00
Regular price
4 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The Square D 9007C62B2 is a heavy-duty 2-pole limit switch engineered for robust industrial applications. Featuring a plug...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 9007C62B2
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Schneider Electric
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 9007C62B2

Description / Specifications

Description

The 9007C62B2 is a heavy-duty, 1-pole limit switch by Square D. It features a plug-in body and a rotary-type head, designed for reliable performance in various industrial applications. With a long lifespan, it boasts an electrical durability of 1,000,000 cycles and mechanical durability of 10,000,000 cycles, ensuring prolonged operational efficiency.

This limit switch is rated 4 and 13 NEMA, featuring a sturdy zinc construction on both the head and body, enhancing durability and resilience in challenging environments.





Technical Specifications



Part #

9007C62B2

Category

Sensors & Switches

Subcategory

Limit Switch

Product specific application

Standard box

Device short name

9007C

Body type

Plug-in

Head type

Rotary head

Material

Metal

Fixing mode

By the body

Movement of operating head

Rotary

Type of operator

Zinc spring return without operating lever (-)9007C lever

Switch actuation

CW and CCW from left and right

Type of approach

Lateral approach, 1 or 2 programmable direction

Electrical connection

Screw-clamp terminals (AWG 22...AWG 12), 1…2

Cable entry

1 entry for 1/2" - 14 NPT conforming to ANSI B1.20.1

Number of poles

2

Contacts type and composition

2(NC-NO)

Contact operation

Snap action

Positive opening

Without

Sale per indivisible quantity

1

Body material

Zinc

Head material

Zinc

Function available

-

Switch function

DPDT-DB

Contact form

Form ZZ

Contacts material

Silver contacts

Tripping angle

10 °

Maximum displacement angle

90 °

Repeat accuracy

#ERROR!

[Ithe] conventional enclosed thermal current

10 A

Short-circuit protection

10 A by CC fuse, protection type: non-time delay

Electrical durability

1000000 cycles

Local signalling

Without

Mechanical durability

10000000 cycles

Width

39.37 mm

Height

102.11 mm

Depth

63.50 mm

Net weight

0.57 kg

Shock resistance

60 gn for 9 ms conforming to IEC 60068-2-27

Vibration resistance

25 gn (f= 10…150 Hz) conforming to IEC 60068-2-6

IP degree of protection

IP67 conforming to IEC 60529

Electrical shock protection class

Class 0 conforming to IEC 61140

Ambient air temperature for operation

-29…85 °C for standard environment

Ambient air temperature for storage

-29…85 °C

Environmental characteristic

Standard environment

Protective treatment

Epoxy powder coat



Information About 9007C62B2

The Square D 9007C62B2 is a heavy-duty 2-pole limit switch featuring a plug-in body and rotary-type head, designed to withstand demanding industrial environments. With a long lifespan, it offers an electrical durability of 1,000,000 cycles and mechanical durability of 10,000,000 cycles, ensuring reliable performance over extended periods.





Manufacturer information

Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.

IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
