A06B-6055-H422 | Ge Fanuc AC Spindle Drive
- Regular price
- $4,109.00
- Sale price
- $4,109.00
- Regular price
-
Couldn't load pickup availability
Do you need more quantity?
Product Description P/N: A06B-6055-H422
Description
The A06B-6055-H422 is a GE Fanuc AC spindle drive designed for precise and reliable spindle motor control. With robust performance capabilities, it excels in high-demand industrial environments, ensuring efficient and accurate spindle operation. This drive integrates seamlessly into control systems, enhancing overall machining precision.
Technical Specifications
| Brand | GE FANUC |
| Category | Servo Products |
| Part Number | A06B-6055-H422 |
| Subcategory | CNC Motor/Control |
| Series | Alpha |
| Power Supply | 283-325 VAC, 3-phase, 50/60 Hz |
| Control System | Digital |
| Continuous Output Current | 17 A |
| Maximum Output Current | 24 A |
| Rated Output | 7.5 kW (10 HP) |
| Maximum Output | 9.0 kW (12 HP) |
| Speed Control Range | 0 to 6000 min^-1 (rpm) |
| Dimensions | 290 mm (W) x 290 mm (H) x 160 mm (D) |
| Ambient Temperature | 0 to 45°C (32 to 113°F) |
| Humidity | 90% or less (non-condensing) |
| Installation | Indoor use only |
Information About A06B-6055-H422
The A06B-6055-H422 is a GE Fanuc AC spindle drive from the Alpha series, designed for high-performance spindle motor control in CNC applications. It operates with a power supply of 283-325 VAC, 3-phase, 50/60 Hz. The drive features a digital control system for precise management and delivers a continuous output current of 17 A with a maximum output current of 24 A. It provides a rated output of 7.5 kW (10 HP), with a maximum output of 9.0 kW (12 HP). The spindle drive supports a speed control range from 0 to 6000 rpm. Its dimensions are 290 mm (W) x 290 mm (H) x 160 mm (D). The unit operates efficiently within an ambient temperature range of 0 to 45°C (32 to 113°F) and can handle humidity up to 90% or less (non-condensing). It is intended for indoor use only, ensuring reliable performance in controlled environments.
Manufacturer information
GE FANUC, now part of Emerson Automation Solutions, was a leading provider of industrial automation and control systems. Known for innovative solutions, GE FANUC played a key role in advancing manufacturing, offering a range of products including PLCs, CNCs, and HMI solutions.
