A1212CHNFSS | Nvent Hoffman Continuous Hinge with Clamps Junction Box Type
- Regular price
- $362.00
- Sale price
- $362.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: A1212CHNFSS
Description
The nVent HOFFMAN A1212CHNFSS is a stainless steel junction box measuring 12 inches in height, 12 inches in width, and 6 inches in depth.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand |
Nvent Hoffman |
| Category | Panel Accessories |
| Part Number | A1212CHNFSS |
| Subcategory | Panel Enclosures |
| Body Thickness | 1.98 mm |
| Cover Type | Continuous Hinged with Clamp |
| Material | Stainless Steel |
| Size | 12.00x12.00x6.00 in |
| Type | Two Lock, Single Door |
| Body Gauge | 14 |
| Cover Gauge | 16 |
| Mounting Type | Wall |
| Standard | 12,4,4X,50E Listed,CUL Listed Per CSA C22.2 No 94,File No. E27567,File No. E61997,NEMA/EEM,Type 3R,UL 50,UL 508A Listed |
| Finish | Brushed |
| Weight | 12.8 lbs |
Information About A1212CHNFSS
The nVent HOFFMAN A1212CHNFSS is a stainless steel junction box designed for both indoor and outdoor applications, providing robust protection for electrical components in corrosive environments.
Key Features:
-
Construction: Made from 16- and 14-gauge Type 304 stainless steel with seams that are continuously welded and ground smooth for enhanced durability.
-
Design: Features a continuous hinge with stainless steel screw-down clamps on three sides of the door, ensuring a secure and reliable seal. The seamless foam-in-place gasket further enhances its protective capabilities.
-
Accessibility: The stainless steel continuous hinge pin can be pulled to remove the door easily, facilitating straightforward access for maintenance or modifications.
-
Mounting: Equipped with weldnuts for mounting optional panels and terminal block kits, along with bonding provisions on both the door and body. External wall-mounting brackets are included for easy installation.
Specifications:
-
Dimensions: 12 inches in height, 12 inches in width, and 6 inches in depth.
-
Material Finish: Smooth #4 brushed finish on the cover and sides.
-
Industry Standards Compliance:
- UL 50, 50E Listed; Type 3R, 4, 4X, 12
- cUL Listed per CSA C22.2 No. 94; Type 3R, 4, 4X, 12
- UL 508A Listed; Type 3R, 4, 4X, 12
- NEMA/EEMAC Type 3R, 4, 4X, 12, 13
- CSA File No. 42184; Type 4, 4X, 12
- IEC 60529, IP66
These certifications ensure the enclosure's suitability for various demanding environments, offering protection against dust, water, and corrosion.
Description
The nVent HOFFMAN A1212CHNFSS is a stainless steel junction box measuring 12 inches in height, 12 inches in width, and 6 inches in depth.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand |
Nvent Hoffman |
| Category | Panel Accessories |
| Part Number | A1212CHNFSS |
| Subcategory | Panel Enclosures |
| Body Thickness | 1.98 mm |
| Cover Type | Continuous Hinged with Clamp |
| Material | Stainless Steel |
| Size | 12.00x12.00x6.00 in |
| Type | Two Lock, Single Door |
| Body Gauge | 14 |
| Cover Gauge | 16 |
| Mounting Type | Wall |
| Standard | 12,4,4X,50E Listed,CUL Listed Per CSA C22.2 No 94,File No. E27567,File No. E61997,NEMA/EEM,Type 3R,UL 50,UL 508A Listed |
| Finish | Brushed |
| Weight | 12.8 lbs |
Information About A1212CHNFSS
The nVent HOFFMAN A1212CHNFSS is a stainless steel junction box designed for both indoor and outdoor applications, providing robust protection for electrical components in corrosive environments.
Key Features:
-
Construction: Made from 16- and 14-gauge Type 304 stainless steel with seams that are continuously welded and ground smooth for enhanced durability.
-
Design: Features a continuous hinge with stainless steel screw-down clamps on three sides of the door, ensuring a secure and reliable seal. The seamless foam-in-place gasket further enhances its protective capabilities.
-
Accessibility: The stainless steel continuous hinge pin can be pulled to remove the door easily, facilitating straightforward access for maintenance or modifications.
-
Mounting: Equipped with weldnuts for mounting optional panels and terminal block kits, along with bonding provisions on both the door and body. External wall-mounting brackets are included for easy installation.
Specifications:
-
Dimensions: 12 inches in height, 12 inches in width, and 6 inches in depth.
-
Material Finish: Smooth #4 brushed finish on the cover and sides.
-
Industry Standards Compliance:
- UL 50, 50E Listed; Type 3R, 4, 4X, 12
- cUL Listed per CSA C22.2 No. 94; Type 3R, 4, 4X, 12
- UL 508A Listed; Type 3R, 4, 4X, 12
- NEMA/EEMAC Type 3R, 4, 4X, 12, 13
- CSA File No. 42184; Type 4, 4X, 12
- IEC 60529, IP66
These certifications ensure the enclosure's suitability for various demanding environments, offering protection against dust, water, and corrosion.
