ABB 1SVR427057R0000 CP-T Industrial DIN Rail Power Supply
- Regular price
- $847.00
- Sale price
- $847.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 1SVR427057R0000
Description
The ABB 1SVR427057R0000 is a CP-T 24/40.0 switching power supply that converts three-phase AC input into 24 VDC for industrial control equipment. Its single output provides 40 A and 960 W for powering automation devices and associated DC loads.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ABB |
| Category | Power Supplies |
| Part Number | 1SVR427057R0000 |
| Subcategory | DIN Rail Power Supplies |
| Conversion Type | Primary switch mode AC/DC |
| Rated Input Voltage | 400–500 VAC, three-phase |
| Operating AC Input Range | 340–575 VAC, three-phase |
| Alternative DC Input Range | 480–820 VDC |
| Input Frequency | 47–63 Hz |
| Number of Outputs | 1 |
| Rated Output Voltage | 24 VDC |
| Output Adjustment Range | 22.5–28.5 VDC |
| Rated Output Current | 40 A |
| Rated Output Power | 960 W |
| Mounting Type | DIN rail |
| Protection Rating | IP20 |
| Dimensions (H × W × D) | 131 × 276 × 121 mm |
| Weight | 3.27 kg (7.22 lb) |
Information About 1SVR427057R0000
The 1SVR427057R0000 is part of ABB’s CP-T range of primary switch mode power supplies. Its enclosed DIN rail construction supports installation within industrial electrical cabinets. A front-mounted adjustment potentiometer allows the output voltage to be set for the connected equipment. Active current balancing supports parallel operation, while an optional CP-A RU module enables redundant supply arrangements.
Key Features:
- Three-Phase Input: Accepts a rated 400–500 VAC supply within a wider operating range of 340–575 VAC.
- Single DC Output: Provides nominal 24 VDC power through one output circuit.
- Output Capacity: Supplies 40 A with a rated output power of 960 W.
- Adjustable Voltage: Includes a front-face potentiometer for output voltage adjustment.
- Parallel Operation: Supports active current balancing between connected supplies.
- Convection Cooling: Dissipates heat without an internal cooling fan.
- Output Protection: Incorporates overload and short-circuit protection with hiccup-mode operation.
- Output Status Signal: Provides a solid-state signalling contact for monitoring the output voltage condition.
The 1SVR427057R0000 delivers the reliability and precision required for DC power distribution in industrial automation and machine control systems.
