ABB ACS320-03U-08A8-4 5 HP HVAC Variable Frequency Drive
- Regular price
- $1,299.00
- Sale price
- $1,299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: ACS320-03U-08A8-4
Description
The ABB ACS320-03U-08A8-4 is a variable frequency drive designed to regulate AC motor speed in heating, ventilation, and air conditioning (HVAC) systems. Rated for 5 HP applications, it provides controlled operation of pumps and fans in commercial and industrial building systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ABB |
| Category | HVAC Controls & Electrical |
| Part Number | ACS320-03U-08A8-4 |
| Subcategory | Variable Frequency Drive |
| Product Series | ACS320 |
| Product ID | 3AUA0000039662 |
| Rated Power | 5 HP |
| Input Voltage | 380–480 VAC |
| Input Phase | Three-phase |
| Nominal Output Current | 8.8 A |
| Frame Size | R1 |
| Protection Rating | IP20 / Open Type |
| Communication | Embedded BACnet MS/TP |
| Net Weight | 1.179 kg |
Information About ACS320-03U-08A8-4
The ACS320-03U-08A8-4 is part of ABB’s ACS320 series of compact AC drives developed for HVAC pump and fan applications. Its three-phase power configuration supports installations using 380–480 V AC supplies, with a nominal output current of 8.8 A. The drive incorporates HVAC-oriented control functions, including PID regulation and embedded BACnet MS/TP communication for integration with compatible building management systems. Its parameter-based configuration supports adaptation to different motor-control requirements in ventilation, water circulation, and other building-service applications.
Key Features:
- Motor Speed Control: Adjusts AC motor speed to match system operating requirements.
- HVAC Applications: Designed for pump, supply fan, exhaust fan, and condenser fan control.
- Power Rating: Supports 5 HP applications under the specified UL rating.
- Three-Phase Input: Designed for 380–480 V AC supply systems.
- Output Current: Provides a nominal output current rating of 8.8 A.
- BACnet Communication: Embedded BACnet MS/TP supports compatible building management system integration.
- Compact Mounting: R1 frame design supports wall or panel installation, subject to installation requirements.
The ACS320-03U-08A8-4 delivers the reliability and precision required for HVAC motor speed regulation, pump control, and fan operation.
