ABB DSDO-115 32-Channel 24VDC S100 I/O Digital Output Board
- Regular price
- $2,107.00
- Sale price
- $2,107.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: DSDO-115
Description
The ABB DSDO-115 is a 32-channel digital output board designed for use with ABB S100 I/O systems and compatible industrial automation equipment. It provides 24 VDC transistor outputs for switching discrete field devices such as relays, contactors, indicators, and other control components. The board incorporates opto-isolation and short-circuit protection to support reliable signal switching within ABB Advant and related control-system installations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ABB |
| Category | Industrial Automation |
| Part Number | DSDO-115 |
| Subcategory | Digital Output Modules |
| Product Family | S100 I/O |
| Product Type | Digital Output Board |
| Number of Channels | 32 Digital Outputs |
| Output Type | Transistor |
| Output Voltage | 24 VDC |
| Maximum Output Current | 150 mA per channel |
| Output Protection | Short-Circuit Protected |
| Isolation | Opto-Isolated |
| Compatible Connection Units | DSTD 108, DSTD 108L, DSTD 110A, DSTD 190 |
| System Application | ABB Advant OCS / S100 I/O |
| Typical Application | Discrete Industrial Control and Switching |
| Weight | 0.88 lb |
Information About DSDO-115
The DSDO-115 is a digital output module within the ABB S100 I/O product family, developed for applications requiring a high number of discrete control signals. It provides 32 output channels, with each channel using a transistor output designed for 24 VDC operation and loads of up to 150 mA per channel. The outputs are opto-isolated and protected against short circuits, helping separate the control electronics from connected field circuits and protect the output stages during abnormal conditions. The module can be integrated with compatible DSTD connection units and is intended for use in ABB Advant OCS and other compatible industrial control architectures.
Key Features:
- 32 Digital Output Channels: Provides 32 individually controlled discrete outputs for connecting multiple field devices within an industrial automation system.
- 24 VDC Output Operation: Uses a 24 VDC output level suitable for common industrial control and switching circuits.
- Transistor Output Technology: Provides solid-state switching for connected relays, indicators, contactors, and other compatible loads.
- 150 mA Channel Capacity: Each output channel supports loads up to approximately 150 mA under the specified operating conditions.
- Opto-Isolated Design: Provides electrical separation between the control circuitry and the connected output circuits.
- Short-Circuit Protection: Incorporates output protection designed to reduce the risk of damage from short-circuit conditions.
- S100 I/O Compatibility: Designed specifically for integration with ABB S100 I/O control-system architectures and associated equipment.
- DSTD Connection Support: Can be used with compatible DSTD termination and connection units for field wiring integration.
The DSDO-115 delivers the reliability and precision required for industrial digital output control, discrete signal switching, machine automation, and ABB S100 I/O applications.
