ABB XT3NU3200AFF000XXX Tmax XT Thermal Magnetic Circuit Breaker
- Regular price
- $1,387.00
- Sale price
- $1,387.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: XT3NU3200AFF000XXX
Description
The ABB XT3NU3200AFF000XXX is a three-pole molded case circuit breaker with a 200 A thermal-magnetic trip unit for electrical distribution protection. It interrupts overloads and short circuits, with a rated interrupting capacity of 25 kA at 480 VAC.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ABB |
| Category | Circuit Breaker |
| Part Number | XT3NU3200AFF000XXX |
| Subcategory | Molded Case Circuit Breaker |
| Series | SACE Tmax XT |
| Frame Type | XT3N 225 |
| Rated Current | 200 A |
| Frame Current Rating | 225 A |
| Number of Poles | 3 |
| Trip Unit | TMF, fixed thermal / fixed magnetic |
| Instantaneous Trip Setting | 2000 A |
| Rated AC Voltage | 600Y/347 VAC |
| Interrupting Capacity at 240 VAC | 50 kA |
| Interrupting Capacity at 480 VAC | 25 kA |
| Interrupting Capacity at 600Y/347 VAC | 10 kA |
| Mounting Type | Fixed / panel |
| Terminal Configuration | Front bolt terminals; supplied without lugs |
| Dimensions (H × W × D) | 150 × 105 × 70 mm |
| Weight | 1.7 kg (3.75 lb) |
Information About XT3NU3200AFF000XXX
The XT3NU3200AFF000XXX is part of ABB’s SACE Tmax XT family and uses the XT3N 225 frame. Its TMF release combines fixed thermal protection with a fixed instantaneous magnetic setting. The fixed installation version has front terminals for integration into distribution equipment. ABB identifies this North American catalog number with product code 1SDA075117R1. ABB
Key Features:
- Rated Current: Provides a 200 A current rating for the protected circuit.
- Three-Pole Configuration: Switches and protects three circuit poles.
- Thermal Overload Protection: Uses a fixed thermal trip element for sustained overcurrent conditions.
- Magnetic Short-Circuit Protection: Includes a fixed instantaneous trip setting of 2000 A.
- Interrupting Capacity: Rated to interrupt 25 kA at 480 VAC.
- XT3N Frame: Uses the Tmax XT3 platform with a 225 A frame rating.
- Front Connections: Incorporates front bolt terminals for equipment wiring.
- Fixed Installation: Designed for panel installation as a fixed circuit breaker.
The XT3NU3200AFF000XXX delivers the reliability and precision required for overload and short-circuit protection in industrial electrical distribution systems.
Description
The ABB XT3NU3200AFF000XXX is a three-pole molded case circuit breaker with a 200 A thermal-magnetic trip unit for electrical distribution protection. It interrupts overloads and short circuits, with a rated interrupting capacity of 25 kA at 480 VAC.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ABB |
| Category | Circuit Breaker |
| Part Number | XT3NU3200AFF000XXX |
| Subcategory | Molded Case Circuit Breaker |
| Series | SACE Tmax XT |
| Frame Type | XT3N 225 |
| Rated Current | 200 A |
| Frame Current Rating | 225 A |
| Number of Poles | 3 |
| Trip Unit | TMF, fixed thermal / fixed magnetic |
| Instantaneous Trip Setting | 2000 A |
| Rated AC Voltage | 600Y/347 VAC |
| Interrupting Capacity at 240 VAC | 50 kA |
| Interrupting Capacity at 480 VAC | 25 kA |
| Interrupting Capacity at 600Y/347 VAC | 10 kA |
| Mounting Type | Fixed / panel |
| Terminal Configuration | Front bolt terminals; supplied without lugs |
| Dimensions (H × W × D) | 150 × 105 × 70 mm |
| Weight | 1.7 kg (3.75 lb) |
Information About XT3NU3200AFF000XXX
The XT3NU3200AFF000XXX is part of ABB’s SACE Tmax XT family and uses the XT3N 225 frame. Its TMF release combines fixed thermal protection with a fixed instantaneous magnetic setting. The fixed installation version has front terminals for integration into distribution equipment. ABB identifies this North American catalog number with product code 1SDA075117R1. ABB
Key Features:
- Rated Current: Provides a 200 A current rating for the protected circuit.
- Three-Pole Configuration: Switches and protects three circuit poles.
- Thermal Overload Protection: Uses a fixed thermal trip element for sustained overcurrent conditions.
- Magnetic Short-Circuit Protection: Includes a fixed instantaneous trip setting of 2000 A.
- Interrupting Capacity: Rated to interrupt 25 kA at 480 VAC.
- XT3N Frame: Uses the Tmax XT3 platform with a 225 A frame rating.
- Front Connections: Incorporates front bolt terminals for equipment wiring.
- Fixed Installation: Designed for panel installation as a fixed circuit breaker.
The XT3NU3200AFF000XXX delivers the reliability and precision required for overload and short-circuit protection in industrial electrical distribution systems.
