AM3042-0E21-0000 | Beckhoff AM3000 Servo Motor, 2.81 Nm, 3500 RPM, Resolver/EnDat/BiSS
- Regular price
- $1,479.00
- Sale price
- $1,479.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: AM3042-0E21-0000
Description
The Beckhoff AM3042-0E21-0000 is a synchronous servo motor from the AM3000 series, delivering a rated torque of 2.81 Nm at speeds up to 3500 min⁻¹. Designed for 400–480 V AC drive systems, it provides up to 13.0 Nm peak torque with convection cooling, making it suitable for highly dynamic industrial motion applications. The motor incorporates resolver, BiSS B, and EnDat 2.1 feedback for precise control and system integration.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Beckhoff |
| Category | Servo Products |
| Part Number | AM3042-0E21-0000 |
| Subcategory | Servo Motor |
| Series | AM3000 |
| Motor Type | Synchronous low-inertia servo motor |
| Rated Torque | 2.81 Nm |
| Peak Torque | 13.0 Nm |
| Standstill Torque | 3.35…3.53 Nm (depending on winding) |
| Rated Speed | 3500 min⁻¹ |
| Torque Constant | 1.26 Nm/A |
| Standstill Current | 2.74 A |
| Peak Current | 13.7 A |
| Voltage Rating | 400–480 V AC |
| Auxiliary Voltage | 24 V DC (for brake and sensors) |
| Cooling Method | Convection |
| Motor Feedback | Resolver, BiSS B, EnDat 2.1 |
| Flange Code | F4 (87 mm) |
| Motor Length | 2 |
| Shaft | Diameter 19 mm, free shaft end 40 mm |
| Power Output | Approx. 0.9 kW |
| Protection Class | IP64 (with shaft seal), IP65 (housing) |
| Ambient Operating Temp. | 0…+40 °C |
| Weight | 12 lbs (≈5.4 kg) |
Information About AM3042-0E21-0000
The AM3042-0E21-0000 is part of Beckhoff’s AM3000 series of low-inertia synchronous servo motors, optimized for applications demanding high acceleration and precision. It features flange code F4 (87 mm), motor length 2, and a free shaft end of 40 mm with a shaft diameter of 19 mm, ensuring compatibility with compact machine designs. Its torque constant of 1.26 Nm/A provides efficient torque generation, while the standstill torque falls in the 3.35–3.53 Nm range depending on winding configuration. Built for convection cooling, the motor operates in the 400–480 V AC supply range with a 24 V DC holding brake option, ensuring reliability in continuous industrial environments.
Key Features:
- Rated torque: 2.81 Nm continuous torque at 3500 min⁻¹ for standard applications.
- Peak torque: Up to 13.0 Nm for dynamic load conditions.
- Torque constant: 1.26 Nm/A for efficient performance.
- Cooling method: Convection cooling for reliable heat dissipation without forced airflow.
- Feedback systems: Resolver, BiSS B, and EnDat 2.1 supported for precise position and speed control.
- Mechanical design: Flange code F4 (87 mm), motor length 2, shaft diameter 19 mm with free shaft end 40 mm.
- Electrical characteristics: Rated for 400–480 V AC systems, standstill current 2.74 A, peak current 13.7 A.
- Durability: Built with robust construction and military-grade foam packaging for safe handling.
The AM3042-0E21-0000 delivers the performance and reliability required for advanced servo-driven automation solutions.
