AMETEK T-975 Pneumatic Pressure and Vacuum Calibration Hand Pump
- Regular price
- $1,817.00
- Sale price
- $1,817.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: T-975
Description
AMETEK T-975 is a pneumatic hand pump for generating and adjusting pressure or vacuum during instrument calibration. It produces pressure up to 580 psi (40 bar) and vacuum down to −27 inHg.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | AMETEK |
| Category | Calibration Equipment |
| Part Number | T-975 |
| Subcategory | Pneumatic Pressure Pumps |
| Pump Type | Pneumatic hand pump |
| Pressure Range | 0 to 580 psi (0 to 40 bar) |
| Vacuum Range | Down to −27 inHg (−0.91 bar) |
| Test Medium | Air |
| Fine Adjustment Sensitivity | 0.01 psi |
| Pressure Connections | 3/8 in BSP female reference port; device port 1/4 in NPT and 1/4 in BSP female |
| Dimensions | 216 × 121 × 62 mm |
| Standard Hose | 1 m |
| Weight | 1.4 kg |
Information About T-975
The T-975 belongs to AMETEK’s T-900 series of pneumatic calibration pumps. Its button valve switches between pressure and vacuum generation, while a fine-adjust valve supports controlled pressure setting. The pump uses air as the test medium and has two outlet ports for reference and device-under-test connections. It is used with compatible pressure calibrators and instruments during field or bench testing.
Key Features:
- Pressure and Vacuum Generation: Produces up to 580 psi (40 bar) and down to −27 inHg vacuum.
- Button Valve Switching: Switches between pressure and vacuum modes using the control valve.
- Fine Pressure Adjustment: Provides adjustment sensitivity down to 0.01 psi.
- Adjustable Stroke: Allows stroke adjustment to control pressure generation.
- Dual Outlet Ports: Includes separate ports for the reference instrument and device under test.
- Compact Hand Pump: Measures approximately 216 × 121 × 62 mm for portable calibration work.
The T-975 delivers the reliability and precision required for pneumatic pressure and vacuum calibration.
