ANN-80 | Notifier Remote Fire Annunciator with 80-Character Backlit LCD
- Regular price
- $395.00
- Sale price
- $395.00
- Regular price
-
$0.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: ANN-80
Description
The Notifier ANN-80 is a compact remote fire annunciator with an 80-character backlit LCD that replicates the display of a fire alarm control panel (FACP). It provides system status indicators for power, alarm, trouble, supervisory, and silence conditions while supporting remote operation of key control functions. The ANN-80 communicates with the host panel via the ANN-Bus interface and can be installed up to 6,000 ft away.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Notifier |
| Category | Fire Safety |
| Part Number | ANN-80 |
| Subcategory | Fire Alarm |
| Display | 80-character LCD (20 characters x 4 lines), backlit |
| Indicators | AC power, alarm, trouble, supervisory, alarm silence |
| Control Switches | Acknowledge, silence, drill, reset (keyswitch-protected) |
| Communication | ANN-Bus, 2-wire serial (plus power) |
| Distance from Panel | Up to 6,000 ft (1,800 m) |
| Operating Voltage | 18.8 VDC – 38.2 VDC |
| Current Consumption | 39 mA standby, 46 mA trouble, 48 mA alarm, 15 mA AC fail |
| ANN-Bus Rating | 5.5 VDC, 60 mA max |
| Enclosure Supervision | Yes, tamper-protected |
| Certifications | UL S2424, ULC, FM, CSFM 7120-0075:0211, MEA 442-06-E |
| Dimensions | 6.875”W x 5.375”H x 1.375”D (17.46 × 13.65 × 3.49 cm) |
| Mounting Options | Surface or semi-flush to standard boxes |
| Weight | 1.20 lbs |
Information About ANN-80
The ANN-80 is a Notifier remote annunciator designed to extend fire alarm system visibility and control. It features a four-line LCD that displays device type, zone information, custom labels, and real-time status messages from the host FACP. The unit supports essential control operations—such as acknowledge, silence, drill, and reset—secured by a keyswitch to prevent unauthorized access. With support for up to eight ANN-80 annunciators per ANN-Bus, flexible mounting options, and UL/FM approvals, this model is suitable for commercial, institutional, and industrial fire safety applications requiring distributed monitoring and control.
Key Features:
- 80-Character LCD Display: Provides four-line, backlit text that mirrors host panel information.
- Comprehensive Status Indicators: Displays AC power, alarm, trouble, supervisory, and silence conditions.
- Remote Control Functions: Includes acknowledge, signal silence, drill, and system reset switches.
- Keyswitch Security: Restricts operation of control functions and locks annunciator enclosure.
- Flexible Mounting: Supports surface or semi-flush installation to standard wall or electrical boxes.
- Long-Distance Connectivity: Operates up to 6,000 ft from host FACP over ANN-Bus.
- Event Visibility: Displays point-specific alarms, troubles, and supervisory conditions.
- Regulatory Approvals: UL, ULC, FM, CSFM, and MEA certified for fire safety use.
The ANN-80 delivers the reliability and visibility required for distributed fire alarm system monitoring and control.
Description
The Notifier ANN-80 is a compact remote fire annunciator with an 80-character backlit LCD that replicates the display of a fire alarm control panel (FACP). It provides system status indicators for power, alarm, trouble, supervisory, and silence conditions while supporting remote operation of key control functions. The ANN-80 communicates with the host panel via the ANN-Bus interface and can be installed up to 6,000 ft away.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Notifier |
| Category | Fire Safety |
| Part Number | ANN-80 |
| Subcategory | Fire Alarm |
| Display | 80-character LCD (20 characters x 4 lines), backlit |
| Indicators | AC power, alarm, trouble, supervisory, alarm silence |
| Control Switches | Acknowledge, silence, drill, reset (keyswitch-protected) |
| Communication | ANN-Bus, 2-wire serial (plus power) |
| Distance from Panel | Up to 6,000 ft (1,800 m) |
| Operating Voltage | 18.8 VDC – 38.2 VDC |
| Current Consumption | 39 mA standby, 46 mA trouble, 48 mA alarm, 15 mA AC fail |
| ANN-Bus Rating | 5.5 VDC, 60 mA max |
| Enclosure Supervision | Yes, tamper-protected |
| Certifications | UL S2424, ULC, FM, CSFM 7120-0075:0211, MEA 442-06-E |
| Dimensions | 6.875”W x 5.375”H x 1.375”D (17.46 × 13.65 × 3.49 cm) |
| Mounting Options | Surface or semi-flush to standard boxes |
| Weight | 1.20 lbs |
Information About ANN-80
The ANN-80 is a Notifier remote annunciator designed to extend fire alarm system visibility and control. It features a four-line LCD that displays device type, zone information, custom labels, and real-time status messages from the host FACP. The unit supports essential control operations—such as acknowledge, silence, drill, and reset—secured by a keyswitch to prevent unauthorized access. With support for up to eight ANN-80 annunciators per ANN-Bus, flexible mounting options, and UL/FM approvals, this model is suitable for commercial, institutional, and industrial fire safety applications requiring distributed monitoring and control.
Key Features:
- 80-Character LCD Display: Provides four-line, backlit text that mirrors host panel information.
- Comprehensive Status Indicators: Displays AC power, alarm, trouble, supervisory, and silence conditions.
- Remote Control Functions: Includes acknowledge, signal silence, drill, and system reset switches.
- Keyswitch Security: Restricts operation of control functions and locks annunciator enclosure.
- Flexible Mounting: Supports surface or semi-flush installation to standard wall or electrical boxes.
- Long-Distance Connectivity: Operates up to 6,000 ft from host FACP over ANN-Bus.
- Event Visibility: Displays point-specific alarms, troubles, and supervisory conditions.
- Regulatory Approvals: UL, ULC, FM, CSFM, and MEA certified for fire safety use.
The ANN-80 delivers the reliability and visibility required for distributed fire alarm system monitoring and control.
