ASA5510-CSC20-K9 | Cisco Firewall Content Security
- Regular price
- $1,254.00
- Sale price
- $1,254.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: ASA5510-CSC20-K9
Description
The Cisco ASA5510-CSC20-K9 is a security appliance bundle that combines the Cisco ASA 5510 firewall with the CSC-SSM-20 (Content Security and Control Security Services Module).
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cisco |
| Category |
Security
|
| Part Number | ASA5510-CSC20-K9 |
| Subcatecory |
Security Controller
|
| Maximum Firewall Throughput | 300 Mbps |
| Maximum Connections | 50.000 |
| Maximum Connections/second | 6,000 |
| Packets Per Second (64 Byte) |
190,000
|
| Application-layer Security | Yes |
| Layer 2 Transparent Firewalling |
Yes
|
| Maximum 3DES/AES VPN Throughput |
170 Mbps
|
| Maximum Virtual Interfaces (VLANs) |
50 (trunking enabled)
|
| Maximum SSL VPN User Sessions |
250
|
| Integrated ports |
5-10/100
|
| Weight |
23.45 lbs
|
Information About ASA5510-CSC20-K9
The Cisco ASA5510-CSC20-K9 is a versatile security appliance bundle combining the Cisco ASA 5510 Adaptive Security Appliance with the CSC-SSM-20 (Content Security and Control Security Services Module). Designed for small to mid-sized businesses and branch offices, this model delivers advanced firewall protection along with integrated content security features including antivirus, anti-spam, and web filtering. It offers strong VPN capabilities, scalable throughput, and multi-layered threat defense in a compact and manageable form factor.
Key Features:
- Firewall Throughput: Up to 300 Mbps
- VPN Throughput: Up to 170 Mbps (3DES/AES)
- Concurrent Sessions: Up to 50,000
- VPN Peers: Supports up to 250 IPsec VPN peers
- Interfaces: 5x 10/100 Fast Ethernet ports
- High Availability: Supports Active/Standby and Active/Active (with Security Plus license)
- Virtualization: Up to 5 security contexts
- CSC-SSM-20 Module: Integrated content security including antivirus, anti-spyware, anti-spam, and URL filtering
- Security Features: Stateful packet inspection, deep packet inspection, identity-based access policies
- Management: Cisco ASDM (GUI), CLI, and centralized control via Cisco Security Manager
- Deployment Modes: Routed, Transparent, Multi-context, and VPN clustering
- Power Requirements: AC power supply, internal redundant power available
- Form Factor: Rack-mountable 1U chassis
- Operating Range: 0°C to 40°C; 10% to 90% humidity (non-condensing)
This security solution is ideal for organizations seeking a reliable firewall with built-in threat protection and simplified administration. Though now end-of-life, it remains a robust option in legacy environments, with Cisco recommending migration to the ASA 5500-X or Firepower series for enhanced security capabilities.
Description
The Cisco ASA5510-CSC20-K9 is a security appliance bundle that combines the Cisco ASA 5510 firewall with the CSC-SSM-20 (Content Security and Control Security Services Module).
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cisco |
| Category |
Security
|
| Part Number | ASA5510-CSC20-K9 |
| Subcatecory |
Security Controller
|
| Maximum Firewall Throughput | 300 Mbps |
| Maximum Connections | 50.000 |
| Maximum Connections/second | 6,000 |
| Packets Per Second (64 Byte) |
190,000
|
| Application-layer Security | Yes |
| Layer 2 Transparent Firewalling |
Yes
|
| Maximum 3DES/AES VPN Throughput |
170 Mbps
|
| Maximum Virtual Interfaces (VLANs) |
50 (trunking enabled)
|
| Maximum SSL VPN User Sessions |
250
|
| Integrated ports |
5-10/100
|
| Weight |
23.45 lbs
|
Information About ASA5510-CSC20-K9
The Cisco ASA5510-CSC20-K9 is a versatile security appliance bundle combining the Cisco ASA 5510 Adaptive Security Appliance with the CSC-SSM-20 (Content Security and Control Security Services Module). Designed for small to mid-sized businesses and branch offices, this model delivers advanced firewall protection along with integrated content security features including antivirus, anti-spam, and web filtering. It offers strong VPN capabilities, scalable throughput, and multi-layered threat defense in a compact and manageable form factor.
Key Features:
- Firewall Throughput: Up to 300 Mbps
- VPN Throughput: Up to 170 Mbps (3DES/AES)
- Concurrent Sessions: Up to 50,000
- VPN Peers: Supports up to 250 IPsec VPN peers
- Interfaces: 5x 10/100 Fast Ethernet ports
- High Availability: Supports Active/Standby and Active/Active (with Security Plus license)
- Virtualization: Up to 5 security contexts
- CSC-SSM-20 Module: Integrated content security including antivirus, anti-spyware, anti-spam, and URL filtering
- Security Features: Stateful packet inspection, deep packet inspection, identity-based access policies
- Management: Cisco ASDM (GUI), CLI, and centralized control via Cisco Security Manager
- Deployment Modes: Routed, Transparent, Multi-context, and VPN clustering
- Power Requirements: AC power supply, internal redundant power available
- Form Factor: Rack-mountable 1U chassis
- Operating Range: 0°C to 40°C; 10% to 90% humidity (non-condensing)
This security solution is ideal for organizations seeking a reliable firewall with built-in threat protection and simplified administration. Though now end-of-life, it remains a robust option in legacy environments, with Cisco recommending migration to the ASA 5500-X or Firepower series for enhanced security capabilities.
