MS120-8LP-HW | Cisco Gigabit Ethernet Compact Switch
- Regular price
- $721.00
- Sale price
- $721.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: MS120-8LP-HW
Description
The Cisco MS120-8LP-HW is a compact, cloud-managed Layer 2 Gigabit Ethernet switch from the Meraki MS120 series.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cisco |
| Category |
PLCs and Accessories
|
| Part Number | MS120-8LP-HW |
| Subcategory |
PLC Expansion Modules
|
| Total Number of Network Ports | 8 |
| Uplink Port |
Yes
|
| Modular |
Yes
|
| Stack Port |
Yes
|
| Port/Expansion Slot Details | 8 x Gigabit Ethernet Network 2 x Gigabit Ethernet Uplink |
| Media Type Supported | Twisted Pair Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T 1000Base-X |
| Number of Total Expansion Slots | 2 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Layer Supported | 2 |
| Manageable | Yes |
| Form Factor | Wall Mountable Desktop |
| Height | 1.1" |
| Width | 8.7" |
| Depth | 5.9" |
| Weight | 2.76 lbs |
Information About MS120-8LP-HW
The Cisco Meraki MS120-8LP-HW is a compact, cloud-managed Layer 2 access switch designed for small branch offices and space-constrained environments. It offers enterprise-grade networking features with simplified management through the Meraki Dashboard.
Key Features:
-
Form Factor: Compact, fanless design with integrated mounting brackets
-
Ports: 8 × 1GbE RJ45 with PoE/PoE+ support, 2 × 1GbE SFP uplinks
-
PoE Budget: 67W total, supporting up to 30W per port
-
Switching Capacity: 20 Gbps non-blocking
-
Power Supply: External (90W, MA-PWR-90WAC)
-
Dimensions: 1.1 x 8.74 x 5.91 inches (2.8 x 22.2 x 15 cm)
-
Weight: 2.76 lbs (1.25 kg)
-
Operating Temperature: 0°C to 45°C
-
Management: Cloud-managed via Meraki Dashboard with features like zero-touch provisioning, virtual stacking, and detailed network analytics
-
Security Features: Supports 802.1X authentication, DHCP snooping, MAC whitelisting, and ACLs
The MS120-8LP-HW is ideal for deployments requiring reliable Gigabit connectivity with Power over Ethernet capabilities, all managed through an intuitive cloud interface. Its compact size and silent operation make it suitable for environments where space and noise are considerations.
