ASCO 8345H003 Series 8345 Four-Way Pilot-Operated Brass Solenoid Valve for Pneumatic Control Systems
- Regular price
- $599.00
- Sale price
- $599.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 8345H003
Description
The ASCO 8345H003 is a Series 8345 pilot-operated four-way solenoid valve designed for reliable directional control of compressed air and inert gas in industrial pneumatic systems. It features a brass body, a single-solenoid configuration, and a three-wire Class F coil rated at 10.1 watts for continuous-duty operation. The valve provides dependable switching performance for automation equipment, actuator control, and pneumatic process applications requiring accurate flow direction.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ASCO |
| Category | Valves |
| Part Number | 8345H003 |
| Subcategory | Solenoid Valve |
| Series | 8345 |
| Valve Type | Pilot-Operated Solenoid Valve |
| Valve Function | Four-Way, Two-Position |
| Valve Configuration | Single Solenoid, Spring Return |
| Body Material | Brass |
| Port Size | 1/4 Inch National Pipe Thread |
| Orifice Size | 1/16 Inch |
| Flow Coefficient | Cv 0.09 |
| Compatible Media | Air, Inert Gas |
| Operating Pressure Range | 10 to 150 PSI |
| Maximum Fluid Temperature | 180 °F (82 °C) |
| Power Consumption | 10.1 Watts |
| Coil Insulation Class | Class F |
| Electrical Connection | Three-Wire Coil |
| Weight | 3.00 lbs |
Information About 8345H003
The 8345H003 is part of the ASCO Series 8345 family of pilot-operated four-way, two-position general service solenoid valves developed for pneumatic control systems. It incorporates a durable brass valve body with one-quarter inch National Pipe Thread ports, a one-sixteenth inch orifice, and a spring-return single-solenoid design that ensures reliable directional switching. This model is intended for air and inert gas service with an operating pressure range of 10 to 150 pounds per square inch and a maximum fluid temperature of 180 degrees Fahrenheit. The compact construction, low power consumption, and industrial-grade sealing materials make it suitable for controlling pneumatic cylinders, automated machinery, process equipment, and industrial actuator assemblies.
Key Features:
- Series 8345 Construction: Designed for industrial pneumatic directional control applications.
- Four-Way Two-Position Operation: Provides reliable control of double-acting pneumatic actuators.
- Pilot-Operated Design: Delivers dependable operation for continuous industrial service.
- Brass Valve Body: Offers durability and corrosion resistance in industrial environments.
- One-Quarter Inch National Pipe Thread Ports: Compatible with standard pneumatic piping systems.
- Three-Wire Solenoid Coil: Uses a Class F insulated coil rated at 10.1 watts for continuous duty.
- Air and Inert Gas Compatibility: Engineered specifically for pneumatic media applications.
- Operating Pressure Range: Supports working pressures from 10 to 150 pounds per square inch.
The 8345H003 delivers the reliability and precision required for industrial pneumatic control systems, automated machinery, actuator operation, and process automation equipment.
