ASCO EF8345G001MO Series 8345 1/4" 4-Way Solenoid Valve 120VAC
Part #:
EF8345G001MO
Manufactured by:
ASCO
- Regular price
- $507.00
- Sale price
- $507.00
- Regular price
-
1 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The ASCO EF8345G001MO is a 1/4-inch 4-way/2-position pilot-operated solenoid valve designed for general service fluid cont...
Read more
We accept:
Couldn't load pickup availability
IQElectro 2-Year Warranty
Warranty for Product #: EF8345G001MO
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
Product Description P/N: EF8345G001MO
Description / Specifications
Description
The ASCO EF8345G001MO is a RedHat Series 8345 general service solenoid valve designed for directional control of air, inert gas, water, and light oil. It features a 4-way/2-position pilot-operated configuration, 1/4-inch female threaded ports, a brass body, and a manual/momentary operator for industrial fluid-control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ASCO |
| Category | Valves |
| Part Number | EF8345G001MO |
| Subcategory | Solenoid Valve |
| Product Type | General Service Solenoid Valve |
| Series | Series 8345 |
| Valve Configuration | 4-Way / 2-Position |
| Operation Type | Single Solenoid, Pilot Operated |
| Operator Type | Manual / Momentary |
| Body Material | Brass |
| Seal Material | NBR |
| Port Size | 1/4 in |
| Connection Type | Female Threaded (FPT) |
| Pressure Orifice Size | 1/16 in |
| Exhaust Orifice Size | 3/32 in |
| Flow Coefficient (Cv) | 0.09 |
| Media | Air, Inert Gas, Water, Light Oil |
| Operating Pressure Range | 10–150 psi |
| Maximum Fluid Temperature | 180°F |
| Ambient Temperature Range | 32–125°F |
| Input Supply Rating | 110 VAC @ 50 Hz / 120 VAC @ 60 Hz |
| Power Rating | 10.1 W |
| Coil Insulation Class | Class F |
| Electrical Connection | 1/2 in Conduit with 18 in Leads |
| Solenoid Enclosure | Explosion-Proof & Watertight |
| NEMA Rating | NEMA 3, 3S, 4, 4X, 6, 6P, 7, 9 |
| Mounting | Any Position |
| Approvals | UL, CSA, CE |
| Rebuild Kit | 314453-MO |
| Coil | 238614-032-D |
| Weight | 2.14 lbs |
Information About EF8345G001MO
Key Features:
- 4-Way Control: Provides a 4-way/2-position configuration for directional fluid control applications.
- Pilot-Operated Design: Uses a single-solenoid pilot-operated mechanism for dependable switching.
- Manual Operator: Includes a manual/momentary operator for convenient local actuation.
- Multiple Media Compatibility: Suitable for air, inert gas, water, and light oil.
- Compact Construction: Designed for general service installations where space-efficient valve control is required.
- Flexible Mounting: Can be installed in any mounting position.
- Brass Valve Body: Provides durable construction for industrial fluid-control service.
- Protected Enclosure: Explosion-proof and watertight solenoid enclosure supports demanding operating environments.
The EF8345G001MO delivers the reliability and performance required for general-purpose industrial directional control applications.
