ATV312H037N4 | Schneider Electric Variable Speed Drive
- Regular price
- $355.00
- Sale price
- $355.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: ATV312H037N4
Description
The Schneider Electric ATV312H037N4 is a 0.37kW (0.5 hp) variable speed drive designed for 3-phase 380-500V supply. It features a 1.5A current rating and supports CANopen and Modbus communication protocols. Ideal for precise control of asynchronous motors in industrial applications, enhancing efficiency and performance.
Technical Specifications
| Brand | Schneider Electric |
| Part Number | ATV312H037N4 |
| Category | Drives |
| Subcategory | Drive |
| Product destination | Asynchronous motors |
| Product specific application | Simple machine |
| Assembly style | With heat sink |
| Component name | ATV312 |
| Motor power kW | 0.37 kW |
| Motor power hp | 0.5 hp |
| [Us] rated supply voltage | 380...500 V (- 15...10 %) |
| Supply frequency | 50...60 Hz (- 5...5 %) |
| Network number of phases | 3 phases |
| Line current | 1.7 A for 500 V 2.2 A for 380 V, 5 kA |
| EMC filter | Integrated |
| Apparent power | 1.5 kVA |
| Maximum transient current | 2.3 A for 60 s |
Information About ATV312H037N4
The Schneider Electric ATV312H037N4 is a reliable variable speed drive specifically designed for asynchronous motors, ideal for applications in simple machines. Featuring a robust assembly style with an integrated heat sink, it ensures effective heat dissipation for prolonged operation.
With a motor power of 0.37 kW (0.5 hp), the ATV312H037N4 operates on a rated supply voltage range of 380-500 V (-15...10%) and a supply frequency of 50-60 Hz (-5...5%). It is tailored for three-phase networks, supporting industrial installations with varying power requirements.
The drive exhibits a line current of 1.7 A at 500 V and 2.2 A at 380 V, delivering an apparent power of 1.5 kVA. It includes an integrated EMC filter, enhancing electromagnetic compatibility and minimizing electrical noise interference.
Capable of handling maximum transient currents of up to 2.3 A for 60 seconds, the ATV312H037N4 ensures reliable operation during peak load conditions, contributing to system stability and longevity. It supports CANopen and Modbus communication protocols, enabling seamless integration into automation systems for enhanced control and monitoring.
In summary, the Schneider Electric ATV312H037N4 variable speed drive combines robust design, efficient thermal management, and advanced control capabilities, making it an ideal choice for optimizing performance and energy efficiency in industrial applications utilizing asynchronous motors.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
