SL4848-VR-D | Automation Direct SOLO 1/16 DIN 24VDC Temperature Controller
- Regular price
- $292.00
- Sale price
- $292.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SL4848-VR-D
Description
The Automation Direct SL4848-VR-D is a SOLO standard temperature controller designed for precise single-loop process temperature regulation. It features a 1/16 DIN panel-mount design with a two-line LED display and supports multiple input types including thermocouples, RTDs, and analog signals. Operating on 24 VDC power, the SL4848-VR-D provides flexible control modes and multiple relay and pulse outputs for heating and cooling applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Automation Direct |
| Category | Process Control |
| Part Number | SL4848-VR-D |
| Subcategory | Temperature Controllers |
| Series | SOLO |
| Mounting | Panel mount |
| Mounting Size | 1/16 DIN |
| Display Type | 2-line LED |
| Operating Voltage | 24 VDC |
| Input Current Range | 0–20 mA, 4–20 mA |
| Input Voltage Range | 0–5 VDC, 0–10 VDC, 0–50 mVDC |
| Thermocouple Types | J, K, T, N, E, R, S, B, L, U, TXK |
| RTD Types | Pt100, JPt100 |
| Control Modes | PID, ON/OFF, ramp/soak, manual |
| Control Function | Single loop, heat only, cool only, heat/cool |
| Outputs | 11–15 VDC pulse, 5A SPST relay, (2) 3A SPST relays |
| Communication | RS-485 |
| Weight | 0.8 lb |
Information About SL4848-VR-D
The SL4848-VR-D is part of the SOLO 1/16 DIN temperature controller series engineered for compact panel installations. It accepts a broad range of temperature and analog inputs, including common thermocouple types, Pt100/JPt100 RTDs, and voltage or current signals. The controller supports PID, ON/OFF, ramp/soak, and manual control modes to accommodate various industrial process requirements. With RS-485 communication capability and multiple relay and pulse outputs, it integrates easily into automated temperature control systems.
Key Features:
- 1/16 DIN Panel Mount Design: Compact form factor for standard control panel cutouts.
- Dual-Line LED Display: Clear process and setpoint indication on a two-line screen.
- Multi-Signal Input Support: Accepts thermocouples, RTDs, and voltage/current signals.
- Flexible Control Modes: Supports PID, ON/OFF, ramp/soak, and manual operation.
- Multiple Output Options: Includes 11–15 VDC pulse output, 5A SPST relay, and dual 3A SPST relays.
- RS-485 Communication: Enables integration with supervisory control and monitoring systems.
- 24 VDC Operation: Designed for low-voltage industrial control power systems.
The SL4848-VR-D delivers the reliability and precision required for industrial temperature control and process regulation applications.
