B&R X20AI1744 X20 Series Strain Gauge Analog Input Module 24-bit
- Regular price
- $1,399.00
- Sale price
- $1,399.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: X20AI1744
Description
The B&R X20AI1744 is a high-precision analog input module designed for industrial automation systems. It features a single full-bridge strain gauge input with a 24-bit analog-to-digital converter, enabling highly accurate measurement of load cells and strain gauges. The module supports configurable data output rates and filtering, making it suitable for demanding measurement and control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | B&R |
| Category | PLCs/Machine Control |
| Part Number | X20AI1744 |
| Subcategory | PLC Module/Rack |
| Series | X20 Series |
| Module Type | Analog Input Module |
| Input Type | Full-Bridge Strain Gauge |
| Number of Inputs | 1 |
| Converter Resolution | 24-bit |
| Data Output Rate | 0.1 Hz to 7.5 kHz |
| Input Filter | Configurable (up to 5 kHz) |
| Operating Modes | Synchronous Mode, Multiple Sampling |
| Supported Load Cell Types | 4-wire and 6-wire |
| Supply Voltage | 24 VDC |
| Operating Temperature | -40°C to 80°C |
| Protection Rating | IP20 |
| Weight | 0.04 lbs |
Information About X20AI1744
The X20AI1744 is part of the B&R X20 series modular I/O system used in programmable logic controller (PLC) environments. It is specifically designed for applications requiring precise measurement from strain gauges or load cells. The module supports both 4-wire and 6-wire strain gauge configurations and incorporates compensation techniques to eliminate measurement inaccuracies caused by component tolerances, bridge voltage variations, and offset errors. With configurable sampling rates and filtering, the device enables reliable data acquisition even in dynamic industrial processes.
Key Features:
-
Strain Gauge Input Module: Designed for accurate measurement of load cells and strain gauges.
-
24-Bit Converter Resolution: Provides high-precision analog signal measurement.
-
Configurable Sampling Rate: Adjustable data output from 0.1 Hz up to 7.5 kHz.
-
Full-Bridge Input Support: Compatible with both 4-wire and 6-wire strain gauge load cells.
-
Measurement Compensation: Eliminates errors caused by component tolerances and voltage variations.
-
Configurable Filtering: Allows optimized signal processing for stable measurements.
-
Special Operating Modes: Supports synchronous mode and multiple sampling.
-
Compact X20 I/O System Design: Suitable for modular PLC automation systems.
The X20AI1744 provides accurate and stable measurement performance for industrial weighing, force measurement, and strain monitoring systems.
