BAB2025 | Eaton 25 Amp Circuit Breaker

The BAB2025 is an Eaton thermal magnetic circuit breaker with a current rating of 25 amps. This circuit breaker operates at a voltage of 240 volts and is designed with two poles. It is constructed to provide reliable overcurrent protection through the thermal magnetic tripping mechanism.

The BAB2025 model is part of Eaton's extensive range of circuit breakers, known for their durability and efficient performance in electrical systems. The two-pole configuration ensures effective disconnection of electrical circuits, thereby enhancing safety during overload or short-circuit conditions. This design is particularly suited for residential, commercial, and light industrial applications where a 25-amp current capacity is required.

Thermal magnetic circuit breakers like the BAB2025 operate using a combination of thermal and magnetic effects to protect electrical circuits. The thermal mechanism responds to prolonged overcurrent conditions by heating a bimetallic strip, which then bends and triggers the trip mechanism. The magnetic mechanism provides instantaneous protection against short-circuits by utilizing an electromagnet that actuates the trip mechanism when a high current flows through the circuit.
