Balluff BIC0071 Remote Inductive Coupler IO-Link 1.1 5 mm
- Regular price
- $499.00
- Sale price
- $499.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BIC0071
Description
The Balluff BIC0071 is a remote inductive coupler designed for contactless, bidirectional transmission of power and IO-Link data across an air gap. It supports a transmission distance of up to 5 mm and connects with compatible coupler bases to enable flexible communication in industrial automation systems.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|
Brand |
Balluff |
|
Category |
Automation Control Components |
|
Part Number |
BIC0071 |
|
Subcategory |
Inductive Couplers |
|
Model |
BIC 2B0-ITA50-Q40KFU-SM4A5A |
|
Product Type |
Remote Inductive Coupler |
|
Function |
IO-Link Signal Transmission |
|
Signal Type |
Bidirectional |
|
Interface |
IO-Link 1.1 |
|
Transfer Rate |
COM2, 38.4 kBaud |
|
Transmission Distance |
0–5 mm |
|
Process Data Input |
0–32 bytes |
|
Minimum Process Data Cycle |
2 ms |
|
Additive Cycle Time |
Device + 2.0 ms |
|
Output Voltage |
24 VDC |
|
Rated Output Current |
500 mA |
|
Maximum Output Current |
5 A for 0.05 ms |
|
Connection |
M12 × 1 female connector, 5-pin |
|
Housing Material |
PBTP |
|
Protection Rating |
IP67 |
|
Ambient Temperature |
-5 to 65 °C |
|
Storage Temperature |
-25 to 70 °C |
|
Dimensions |
40 × 40 × 62 mm |
|
Approvals |
CE, UKCA, cULus, WEEE |
|
Weight |
0.4 lb |
Information About BIC0071
The BIC0071 belongs to Balluff’s BIC series of non-contact inductive coupling devices and corresponds to model BIC 2B0-ITA50-Q40KFU-SM4A5A. It functions as the remote component and supports IO-Link 1.1 communication at COM2 transfer rates of 38.4 kBaud. The unit provides a 24 VDC output and uses a 5-pin M12 female connector. Its PBTP housing and IP67 protection rating support operation in industrial environments.
Key Features:
-
Contactless Data Transmission: Transfers data across an air gap without conventional electrical plug contacts.
-
Bidirectional Communication: Supports two-way IO-Link data transmission between compatible components.
-
Transmission Distance: Operates across a gap of 0–5 mm.
-
IO-Link Compatibility: Supports IO-Link 1.1 and COM2 communication at 38.4 kBaud.
-
Process Data Capacity: Supports up to 32 bytes of process data input and 32 bytes of process data output.
-
Electrical Connection: Uses a 5-pin M12 × 1 female connector.
-
Coupler Compatibility: Designed for use with compatible Balluff BIC0070 and BIC0072 coupler bases.
-
Environmental Protection: Provides IP67 protection and operates from -5 to 65 °C.
The BIC0071 delivers the reliability and precision required for contactless data transmission, flexible machine connections, and industrial automation systems.
