Balluff BNS 819-B02-R08-40-11 Mechanical Limit Switch with Two Roller Actuators
- Regular price
- $419.00
- Sale price
- $419.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BNS 819-B02-R08-40-11
Description
The Balluff BNS 819-B02-R08-40-11 is a mechanical limit switch designed for position detection and switching in industrial automation systems. It features two roller-operated switching positions with snap contacts, supporting reliable mechanical actuation in machinery and positioning applications. Its anodized aluminum housing and IP67 protection rating make it suitable for demanding industrial environments.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|
Brand |
Balluff |
|
Category |
Automation Control Components |
|
Part Number |
BNS 819-B02-R08-40-11 |
|
Subcategory |
Mechanical Limit Switch |
|
Series |
BNS |
|
Switching Positions |
2 |
|
Actuator Type |
Roller |
|
Contact Version |
Snap contact |
|
Switching Function |
Single-pin changeover |
|
Continuous Current |
5 A |
|
Rated Operating Voltage |
250 VAC |
|
Switching Rate |
200 switching operations/min |
|
Switch Position Spacing |
8 mm |
|
Approach Direction |
Longitudinal, parallel to attachment surface |
|
Approach Speed |
60 m/min |
|
Installation |
Vertical |
|
Connection Type |
Screw terminal |
|
Housing Material |
Anodized aluminum |
|
Dimensions |
40 × 34 × 48 mm |
|
Ambient Temperature |
-5 to 85 °C |
|
Protection Rating |
IP67 |
|
Functional Safety |
B10d: 10 million switching cycles |
|
Approvals and Conformity |
CE, UKCA, CCC, WEEE |
|
Basic Standard |
IEC 60947-5-1 |
|
Weight |
1.00 lb |
Information About BNS 819-B02-R08-40-11
The BNS 819-B02-R08-40-11 is part of Balluff’s BNS series of mechanical position switches and row-position counters. Its two roller actuators operate through a mechanical switching mechanism with single-pin changeover contacts. The switch supports a continuous current of 5 A and a rated operating voltage of 250 VAC. Screw-terminal connections provide a conventional wiring method for industrial control circuits.
Key Features:
-
Two Roller Switching Positions: Provides two mechanical switching points for position detection.
-
Snap-Contact Mechanism: Supports reliable switching during mechanical actuation.
-
Anodized Aluminum Housing: Offers a durable enclosure for industrial installation.
-
5 A Continuous Current: Supports the specified current rating for the switching contacts.
-
250 VAC Rated Voltage: Designed for AC control applications within its rated limits.
-
IP67 Protection: Protects against dust ingress and temporary immersion when properly installed.
-
Vertical Installation: Supports vertical mounting with longitudinal approach parallel to the attachment surface.
-
Industrial Temperature Range: Operates in ambient temperatures from -5 to 85 °C.
The BNS 819-B02-R08-40-11 delivers the reliability and precision required for industrial position monitoring, machine control, and mechanical limit detection.
